- Page 1 PD-8000-RSC PD-8000-RSC Rotary Shouldered Rotary Shouldered Pin Connection Pin Connection OPERATION MANUAL ® Thread Inspection...
- Page 2 LPP templates based on specific TPI, TPF, and Thread forms. The PD-8000-RSC gage measures the deviation from nominal pitch diameter for the connector being inspected. The gage uses fixed and a moveable contact balls that are set into the thread’s helical path at a predetermined location.
- Page 3 This is the location where the fixed contact ball of the PD-8000-RSC gage will be placed when measuring the pitch diameter. 6. Repeat steps 4 and 5 to verify proper template location.
- Page 4 Measuring the Pitch Diameter of the Pin Connector 3. With the lower arm loose, slide the arm toward the indicator approximately .100” and tighten the lock screw using a 1/8” Allen wrench. This will preload the indicator .100” as the gage is zeroed. 4.
- Page 5 DATA ON・OFF ◇Key pressing method ・Power On Press（within 2 sec.） ・ Holding displayed value or in ⇔ mm Press and hold External output of displayed value (2sec. or more) Power Off ⇔ （in/mm model only) Parameter Setting Mode ABS mode INC mode （Preset ）...
- Page 6 HOW TO CHANGE RESOLUTION MODE 1) PRESS AND HOLD MODE BUTTON FOR MORE THAN TWO SECONDS MODE 2) PRESS(DON’T HOLD) MODE BUTTON TWICE Press（within 2 sec.） A BLINKING res. WILL BE DISPLAYED Press and hold (2sec. or more) 3) PRESS THE SET BUTTON (THE res. ON DISPLAY WILL STOP BLINKING) MODE 4) PRESS MODE BUTTON TO TOGGLE BETWEEN RESOLUTION [(.00005”, .0001”, 0.005”...
- Page 7 Notes: © 2016 Gagemaker, LP JSS and Gagemaker are registered trademarks of Gage- maker, LP. All rights reserved...
- Page 8 Gagemaker LP, P.O. Box 87709, Houston, Texas 77287-7709 712 East Southmore Ave., Pasadena, Texas 77502 Phone: 713-472-7360 Fax: 713-472-7241 Web site: www.gagemaker.com © 2016 Gagemaker, LP...
