CHAPTER 2. CONNECTION AND PREPARATION
When the Media warps up
If the leading edge of the media is warped up and interferes with the blade tip,
continue to feed the media until it aligns with the indented guideline located behind
the cutting mat. This allows the media to feed properly but reduces the potential
cutting area by 5 mm in the feed direction.
Align the edge of the media with the
guideline (indented) at the rear of the unit.
Media Size
Vinyl and medium that already have backing sheets (liners) can be between 210 and
260 mm in width and up to 1000 mm in length. Scraps of media without backing
sheets (liners), starting from 100 mm in width, can be placed on the carrier sheet
provided with the cutter.
2-3
