Installation 4 functions: Select
Flow diagram
Overhead shower Raindance Rainfall 3jet
# 28411000
Flow diagram
Hand shower Raindance S 120 3jet
# 26530000
Minimum operating pressure •
Components
Mixer installation
iBox universal
C
# 01800180
ShowerSelect valve for
3 functions
# 15764000
iBox universal
D
# 01800180
ShowerSelect thermostat
# 15761000
20
Ceiling
2190 mm
Legend
Rain
1
Whirl
2
RainAir
3
1400 mm
Legend
RainAir
1
1200 mm
Rain
2
Whirl
3
1000 mm
Shower installation
Raindance Rainfall 3jet
A
# 28411000
iBox universal
# 01800180
Raindance Select S 120
B
Hand shower
# 26530000
Shower holder Porter S
# 28331000
Shower hose Isiflex
# 28276000
Hose connection FixFit
E
# 27453000
Waste system Raindrain XXL
F
# 60067000
Floor
3
1
2
DN 20
DN 20
(¾")
(¾")
DN 20
(¾")
DN 15
(½")
DN 20
(¾")
A
+ iBox universal
DN 15
(½")
C
+ iBox universal
D
+ iBox universal
DN 20
(¾")
B
E
F
