Shower system with 3 functions
For instance, overhead shower (2 spray types) and hand shower
ShowerSelect valve
for 3 functions
ShowerSelect Highflow thermostat
Other possible installations
iControl shut-off/diverter valve
Highflow thermostat
Shower system with 4 functions
For instance, overhead shower (3 spray types) and hand shower
ShowerSelect valve
for 3 functions
ShowerSelect Highflow thermostat
for 1 function (bottom) and one
additional function (top)
Other possible installations
Trio/Quattro
shut-off/diverter
valve
Shut-off valve
Highflow
thermostat
Shut-off valve
iBox
®
universal
Examples of uses for
1 to 4 functions
iControl
shut-off/diverter
valve
Highflow
thermostat
Shut-off valve
15
