Hans Grohe iBox universal Planning And Installation page 16

Installation 1 function
Flow diagram
Hand shower Raindance S 120 3jet
# 26530000
Minimum operating pressure •
Components
Mixers
iBox universal
B
# 01800180
ShowerSelect thermostat
# 15762000
Alternative:
Metris thermostat
# 31572000
Other alternatives possible.
16
Ceiling
Legend
RainAir
1
1200 mm
Rain
2
Whirl
3
1000 mm
Showers
Raindance Select S 120
A
# 26530000
Shower holder Porter S
# 28331000
Shower hose Isiflex
# 28276000
Hose connection FixFit
C
# 27453000
Waste system Staro 90
D
# 60056000
Floor
DN 15
(½")
DN 20
(¾")
A
B
+ iBox universal
C
DN 20
(¾")
D
