Installation 3 functions: Standard
Flow diagram
Overhead shower Raindance Rainfall 2jet
# 28433000
Flow diagram
Hand shower Raindance S 120 3jet
# 26530000
Minimum operating pressure •
Components
Mixer installation
Basic set Trio/Quattro
C
# 15981180
Shut-off valve Trio/Quattro S
# 15932000
iBox universal
D
# 01800180
Ecostat S Highflow thermostat
# 15715000
Basic set shut-off valve
E
# 15974180
Shut-off valve S DN15/DN20
# 15972000
Ceiling
2190 mm
Legend
RainAir
1
Rainflow
2
RainAir +
Rainflow
3
1400 mm
Legend
RainAir
1
1200 mm
Rain
2
Whirl
3
1000 mm
Shower installation
800 mm
Raindance Rainfall 2jet
A
# 28433000
iBox universal
# 01800180
Raindance Select S 120
B
3jet Hand shower
# 26530000
Shower holder Porter S
# 28331000
Shower hose Isiflex
# 28276000
Hose connection FixFit
F
# 27453000
Waste system Raindrain XXL
G
# 60067000
Floor
DN 20
DN 15
(¾")
(½")
2
1
DN 20
(¾")
DN 15
(½")
DN 15
(½")
DN 20
(¾")
iBox
®
universal
Installation variant
3 functions
A
+ iBox universal
B
C
D
+ iBox universal
E
F
DN 20
(¾")
G
19
