Application guidelines

Compressor specifications

Frequency converter
specifications

Oil injection control

Bearings lubrication

Technical specifications

Swept
Compressor model volume
(in³/rev)
VSH088 5.39
VSH117 7.13
VSH170 10.39
Mains supply voltage
Supply frequency
Output voltage
Inputs
Programmable outputs
Protection functions
Compressor functions
VSH compressors are equipped with an oil injec-
tion system that ensures the scroll set lubrica-
tion and controls the oil circulation ratio, at all
running speeds. The frequency converter via an
oil injection valve controls this system. The oil
injection valve is a normally closed valve. At low
speed, the valve is closed and the oil is injected
below the orbiting scroll.
Optimal bearings lubrication is ensured by a
gerotor oil pump at all compressor speeds.
Displacement
Min speed 50 Hz 60 Hz
(ft³/h) (ft³/h) (ft³/h)
328 544 657
434 717 869
629 1045 1261
T2: 200 - 240 V +/-10% (3-phase)
T4: 380 - 480 V +/-10% (3-phase)
T6: 525 - 600 V +/-10% (3-phase)
50 / 60 Hz
0 - 100 % of supply voltage
6 digital (0 - 24 V), 2 analogue (-10 / +10 V or 0 / 4 V -20 mA, scalable)
2 digital (0- 24 V), 1 analogue (0-24 V), 2 relay
Over-current protection, over-modulation handling, low / high current
handling
Discharge gas temperature protection, pressostat / thermostat function,
short cycle protection, oil return management
The compressors are delivered with 230V coils.
24V coils are available as accessory (see accesso-
ries page at the end of this document).
Control parameters are factory preset but acces-
sible on the parameter list as read only values.
Oil charge Net weight
Max speed
(oz) (lbs)
(ft³/h)
982 102 130
1292 112 143
1882 228 236
