Application guidelines
Technical specifications
and nominal ratings

Versions

Compressor reference

(indicated on the compressor
nameplate)
6
FRCC.PC.002.A4.22

Specifications

Displacement
Compressor Swept volume
60 Hz
model in /rev
3
3500 rpm
m
NTZ048 2.93 356
NTZ068 4.15 504
NTZ096 5.86 712
NTZ108 6.59 801
NTZ136 8.30 1009
NTZ215 13.12 1594
NTZ271 16.54 2010
(*) Motor code 4 operating conditions: R404A, Evap. temp.: -25°F, Cond. temp.: 105°F, RGT: 40°F, SC: 0°F
For full NTZ data details and capacity tables refer to Online Datasheet Generator: www.danfoss.com/odsg
Available equipment version:
• R1: Rotolock suction and discharge connections, 3/8" flare oil equalisation connection, threaded
sight glass.
NT Z
NT: New low temperature
reciprocating compressors
Z: Polyolester lubricant
Displacement in cm³ / rev.
UL index indicator
Nominal ratings*
60 Hz
Cooling capacity
EER
/hr
3
Btu/h
4888 3.93
8185 4.12
9917 4.12
11470 4.01
15133 3.98
23363 4.20
32430 4.37
048 A 4 L R1 A
Number Oil Net
of charge weight
cylinders oz lbs
1 32 46
1 32 51
2 61 77
2 61 77
2 61 77
4 132 137
4 132 141
Evolution index,
indicating compressor
modi cations
Equipment version
(R1: Rotolock connections,
oil equalisation connection
and sight glass)
Motor protection
(L: Internal Motor Protection)
Motor voltage code
