Application guidelines

CDS302 frequency converter - enclosure B4

380-480 volts – 18-22 kW - IP20 housing
525-600 volts – 18-22 kW - IP20 housing
200-240 volts – 15 kW - IP20 housing
Min 7.87
air space outlet
Min 7.87
air space inlet
Dimensions
9.53
1.38
Air
outlet
23.43
Air
inlet
0.33
0.59
Scale 1:1
18.11
0.31
0.33
Scale 1:1
9.09
7.87
20.39
19.49
Mounting base
FRCC.PC.014.A4.22
