Application guidelines
VSH170- G - H & J
16
FRCC.PC.014.A4.22
Dimensions
24.29
Ø 10.14
10.92
25.67
11.85
Ø 12.51
6.76
2.99
14.60
12
60°
Electrical box
Ø 0.89 inch knockout
Ø 10.47
2.99
4 x holes
13.60
Ø 0.75
11
60°
11.57
10.83
13.90
Grommet
Steel mounting sleeve
Ø 1.99 inch hole
Ø 2.5 inch knockout
Rubber grommet
18.86
All dimensions in inch
HM 8 bolt
Lock washer
Flat washer
Nut
Compressor
base plate
1.10 inch
