Application guidelines

CDS302 frequency converter - enclosure B1

380-480 Volts - 15 kW - IP55 housing
525-600 volts - 15 kW - IP55 housing
9.53
18.9
18
FRCC.PC.014.A4.22
Dimensions
Min 3.94
Air space outlet
Min 3.94
Air space inlet
7.09
1.57
1.34
0.43
0.47
10.24
Air outlet
Air inlet
0.35
scale 1:2
1.46
1.69
1.61
3.31
0.35
0.75
scale 1:2
8.27
0.35
Mounting base
17.87
