SIGMATEK C-DIAS CSCP 012 Manual

Safety cpu
Hide thumbs
Table of Contents

Advertisement

Quick Links

Document changes and version status
Change date
Affected
page(s)
19.12.2013
14
17.02.2016
12
15.05.2017
13
04.12.2017
6, 9, 10, 16
16
17
31.01.2018
9
05.10.2018
14
1.6
Changes/expansions/corrections
Added Standard and Electrical requirements for UL table
Switching-off inductive loads
Specifications of maximum allowable output loads refined
Removed standard IEC 61508
Added chapter „Conformity with EU Standards"
Added „Cat. 4"
Added unit 1/h on PFH
Changed value from 5.81 to 5.8E-09
Changed EMC resistance standard to 61000-6-2:2005
Note Safety outputs protected polarity changed
Note cable capacitance and cable resistance added
C-DIAS SAFETY CPU
value
D
CSCP 012
Version
1.1
1.2
1.3
1.4
1.5
1.6
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C-DIAS CSCP 012 and is the answer not in the manual?

Questions and answers

Related Manuals for SIGMATEK C-DIAS CSCP 012

Summary of Contents for SIGMATEK C-DIAS CSCP 012

  • Page 1 C-DIAS SAFETY CPU CSCP 012 Document changes and version status Change date Affected Changes/expansions/corrections Version page(s) 19.12.2013 Added Standard and Electrical requirements for UL table 17.02.2016 Switching-off inductive loads 15.05.2017 Specifications of maximum allowable output loads refined 04.12.2017 6, 9, 10, 16 Removed standard IEC 61508 Added chapter „Conformity with EU Standards“...

  • Page 2: Table Of Contents

    CSCP 012 C-DIAS SAFETY CPU Contents List of Illustrations ....................4 List of Tables ......................4 Explanation of Safety Symbols................5 Documentation Note .................... 5 Delivery Condition ....................5 Operator Due Diligence ..................5 Test signals for Cross-Circuit Detection ............6 Installation ......................
  • Page 3 C-DIAS SAFETY CPU CSCP 012 Output Power Supply..................17 CSCP 012 Circuit ....................18 LED Display ......................19 Connector Layout ....................20 Connector Plug Coding ..................21 Validation Button ....................22 Explanation of the individual sequences ..............22 Overview of Commands ..................... 24 Handling the micro SD Card ................

  • Page 4: List Of Illustrations

    CSCP 012 C-DIAS SAFETY CPU List of Illustrations Fig. 1: Minimal system of safety-related control ..............7 Fig. 2: CSCP 012 ........................9 Fig. 3: Mechanical dimensions .................... 11 Fig. 4: Inductive load ......................13 Fig. 5: Capacitive load ......................13 Fig.

  • Page 5: Explanation Of Safety Symbols

    Delivery Condition The individual SIGMATEK Safety components are delivered in specific hard and software configurations. Any change of this configuration, which exceeds the options specified in this documentation, is not authorized and invalidates the warranty from SIGMATEK GmbH &...

  • Page 6: Test Signals For Cross-Circuit Detection

    CSCP 012 C-DIAS SAFETY CPU Test signals for Cross-Circuit Detection The module sends pulses in cyclic time intervals to detect a crossed circuit in the outputs. When selecting the actuators, keep in mind that these pulses do not acti- vate the actuators or trigger any diagnostic messages. The pulse signals cannot be deactivated or configured.

  • Page 7: The C-Dias Bus And Connector Layout

    C-DIAS SAFETY CPU CSCP 012 The C-DIAS bus and Connector Layout Signal Signal Signal CDIAS_/MS CDIAS_/RES ------ CDIAS_EE_A2 CDIAS_EE_CLK CDIAS_EE_DAT CDIAS_EE_A1 CDIAS_SYNC CDIAS_EE_IRQ CDIAS_EE_A0 CDIAS_RDY CDIAS_/DEN ------ CDIAS_/RD CDIAS_/WR ------ CDIAS_A6 CDIAS_A7 ------ CDIAS_A4 CDIAS_A5 ------ CDIAS_A2 CDIAS_A3 ------ CDIAS_A0 CDIAS_A1 ------ CDIAS_D6...
  • Page 8 CSCP 012 C-DIAS SAFETY CPU The minimal system of a safety-related control, formed as shown above, with a C-IPC a CMB 081 and a Safety CPU type CSCP 012. The safety-related application is found in the Safety CPU and can run independently of the C-IPC.

  • Page 9: C-Dias Safety Cpu Cscp 012

    C-DIAS SAFETY CPU CSCP 012 C-DIAS Safety CPU CSCP 012 Module Description The Safety CPU component series has the safety integrity level SIL3 and/or SIL CL 3 according to IEC 62061 and/or Performance level e (PL e) according to EN ISO 13849. The Safety CPU component series has: 4 safe inputs (IEC/EN 61131) 2 safe outputs (IEC/EN 61131)

  • Page 10: Designated Use

    CSCP 012 C-DIAS SAFETY CPU Designated Use The CSCP 012 Safety module is designed for use in safety-related applications and meets the required conditions for safety operation in compliance with Perfor- mance level e (PL e), according to EN ISO 13849 and/or SIL 3 according to EN 62061.

  • Page 11: Mechanical Dimensions

    C-DIAS SAFETY CPU CSCP 012 Mechanical Dimensions Fig. 3: Mechanical dimensions Page 11...

  • Page 12: Technical Data

    CSCP 012 C-DIAS SAFETY CPU Technical Data Output specifications All safety outputs are short-circuit protected and specified according to IEC/EN 61131. The outputs are compatible with input of type 1, 2 and 3. Number of … Rated output voltage +24 V DC Output voltage range minimum +18 V maximum +30 V...

  • Page 13: Maximum Inductive Load L (Mh) At Load Current I (A)

    C-DIAS SAFETY CPU CSCP 012 Maximum inductive load L (mH) at load current I (A) Fig. 4: Inductive load Maximum capacitive load C (µF) at load current I (A) Fig. 5: Capacitive load I (A) L (mH) C (µF) 6400 1.25 1600 3.13...

  • Page 14: Input Specifications

    CSCP 012 C-DIAS SAFETY CPU Input specifications The inputs are type 1 according to IEC/EN 61131 Number of … Input voltage +24 V DC Input voltage range including Minimum +18 V Maximum +30 V ripple Low: ≤ +5 V High: ≥ +15 V Signal level Switching threshold Typically +11 V...

  • Page 15: Electrical Requirements

    C-DIAS SAFETY CPU CSCP 012 Electrical requirements The Safety modules' electrical supply must also be provided over the C-DIAS bus in a stand-alone system. A different type and method of supplying energy is not allowed. The C-DIAS bus system's external 24 V supply voltage must be generated by a PELV power supply.

  • Page 16: Safety Conformity

    CSCP 012 C-DIAS SAFETY CPU Safety Conformity Conformity with EU Standards The module has been designed in accordance with the following European Union direc- tives: 2006/42/EG Machinery Directive 2014/30/EU EMC Directive 2011/65/EU RoHS Directive Functional safety standards IEC 62061 SIL 3 or SIL CL 3 EN ISO 13849 PL e / Cat.

  • Page 17: Environmental Conditions

    C-DIAS SAFETY CPU CSCP 012 Environmental conditions Storage temperature -20 to +85 °C Operating temperature 0 to +55 °C Humidity 0 to 95 %, uncondensed EMV stability According to EN 61000-6-2: 2005 (industrial area) Raised requirements according to IEC 26061 Shock resistance EN 60068-2-27 15 g...

  • Page 18: Cscp 012 Circuit

    CSCP 012 C-DIAS SAFETY CPU CSCP 012 Circuit For the functions and LED display, see the following chapter "LED Displays". Fig. 6: CSCP 012 circuit Page 18 05.10.2018...

  • Page 19: Led Display

    C-DIAS SAFETY CPU CSCP 012 LED Display The LED display lights continuously to indicate that the in- and outputs are active. Label Color Function Display 1 – 4 Digital inputs 1 – 4 Green Fast blinking frequency (wiring error, cross circuit... ) (connector X2) 5 –...

  • Page 20: Connector Layout

    CSCP 012 C-DIAS SAFETY CPU Connector Layout Module connection Label Function Connector X1: digital outputs and voltage supply (Group G1) X1 / 1 Digital output 1 X1 / 2 Digital output 2 X1 / 3 +24 V (output supply) X1 / 4 X2: digital inputs X2 / 1 Digital input 1...

  • Page 21: Connector Plug Coding

    C-DIAS SAFETY CPU CSCP 012 Connector Plug Coding Plug X1 Plug X2 Plug X3 Coding pin1 (Pin 1) Socket X1 Coding pin 2 (Pin 2) Plug X2 Codierstift 3 (Pin 3) Socket X3 Fig. 7: Connector plug coding The Phoenix connector sets used are coded at the factory to avoid confusing the connec- tions.

  • Page 22: Validation Button

    CSCP 012 C-DIAS SAFETY CPU Validation Button With the validation button S1, several commands as well as the validation can be execut- • Acknowledging an error and exiting the error status • Deleting a configuration from the Safety CPU • Validating the safety system configuration Inputting commands with the validation button consists of 3 sequential components;...
  • Page 23 C-DIAS SAFETY CPU CSCP 012 Command Selection sequence After the Start sequence, the desired command is selected. This selection is made with button presses in the following time intervals: Minimum press duration is 200 ms, maximum is approximately 3 seconds; the minimum pause between individual button presses is 200 ms, the maximum is 20 seconds.

  • Page 24: Overview Of Commands

    CSCP 012 C-DIAS SAFETY CPU Overview of Commands The number of button presses corresponds to the number of light pulses in LED B during the End sequence. Commands Number of button LED C1 LED C2 LED C3 presses QUIT_ERROR CLR_CFG SET_VERIFIED Table 11: Overview of commands Overview of Module statuses and commands...

  • Page 25: Table 13: Status Transitions

    C-DIAS SAFETY CPU CSCP 012 Executed com- Command function Status after command mand execution QUIT_ERROR A possible error is cancelled in the Safety CPU SW-RESET *) and all Safety modules required by the Safety CPU and the error status is ended. CLR_CFG The configuration in the Safety CPU is deleted.

  • Page 26: Handling The Micro Sd Card

    CSCP 012 C-DIAS SAFETY CPU Handling the micro SD Card An SD card can only be written on with the Safety Designer. A detailed description can be found in the LASAL SafetyDesigner configuration tools documentation. A Safety project, which was programmed with the SafetyDesigner, can be stored on an SD card.
  • Page 27 If an error occurs during the restart, see the following chapter " Restart Error". A micro SD card with a memory capacity of 1 Gigabyte is available from SIGMATEK under the article number 12-630-101 Only micro SD cards that support version 2.0 or higher of the "SDA Physical Layer Specification"...

  • Page 28: Error Response

    CSCP 012 C-DIAS SAFETY CPU Error Response In the event of an error, please consult the chapter "LED Displays", as important infor- mation on the runtime status of the system can be derived from the status and error dis- play. Since errors in general are of a complex nature, do not perform a diagnosis based on the LEDs alone (consult the corresponding chapter in the Safety System Handbook as well).

  • Page 29: Configuration Distribution Error

    C-DIAS SAFETY CPU CSCP 012 During restart, the Safety CPU first runs the POST (Power On Self Test). In the POST, whether the Safety CPU is configured or not is determined. If the Flash memory in the Safety CPU is empty, it changes to the service mode and switches the status LED (ST) to continuously on.

  • Page 30: Troubleshooting

    CSCP 012 C-DIAS SAFETY CPU Troubleshooting • Check all modules in the system for completeness and type conformity • Check that all modules are error-free • Check all connector cables • Cancel the error with the QUIT_ERROR command If the Safety CPU remains in the error status after the QUIT_ERROR command has been executed, it must be retested using the SafetyDesigner.

  • Page 31: Input Circuit

    C-DIAS SAFETY CPU CSCP 012 Input Circuit Digital Input IN 1 to IN 4 Internal logic Fig. 10: Input circuit structure Output Circuit Digital output Internal logik OUT 1 OUT 2 Fig. 11: Output circuit structure Page 31...

  • Page 32: Practical Example Of A Circuit

    CSCP 012 C-DIAS SAFETY CPU Practical Example of a Circuit The following diagram shows the schematic for a processing machine. To implement the application, the following basic requirements must be met. Requirements The installation can only be started manually with the start button S1. For cross- circuit detection, the start button S1 should have a 2-channel connection.

  • Page 33: Implementation

    C-DIAS SAFETY CPU CSCP 012 Implementation • For switch S1, the start button and S2, the Emergency Stop switch, 2 safe in- puts are required for each. • Two safe outputs are needed for control of the relay K1 and the signal lamp P1. •...

  • Page 34: Fig. 13: Example Structure Diagram

    CSCP 012 C-DIAS SAFETY CPU Fig. 13: Example structure diagram The following schematic shows the block diagram corresponding to the Safety CPU wiring in tabular form. Page 34 05.10.2018...

  • Page 35: Connection Diagram

    C-DIAS SAFETY CPU CSCP 012 Connection Diagram CSCP 012 Con- Connection nectors Control relay K1 Control signal light P1 +24 V Normally open start button S1 (B) Normally open start button S1 (B) Normally closed Emergency Stop S2 (A) Normally closed Emergency Stop S2 (b) Output A Clock output B +24 V...
  • Page 36 CSCP 012 C-DIAS SAFETY CPU Page 36 05.10.2018...
