Technical data

10.1

Technical specifications

Technical specifications for MAG 5000/6000
Mode of operation and design Measuring principle
Input
Output
Low flow cut off
Galvanic isolation
Max. measuring error
(incl. sensor and zero point)
Functions
SITRANS FM MAG 5000/6000 IP67
Operating Instructions, 12/2019, A5E02338368-AD
Empty pipe
Excitation frequency
Electrode input impedance
Digital input
Activation time
Current
Current output
Signal range
Load
Time constant
Digital output
Frequency
Pulse (active)
Pulse (passive)
Time constant
Relay output
Time constant
Load
0 to 9.9% of maximum flow
All inputs and outputs are galvanically isolated
MAG 5000
MAG 6000
Flow rate, 2 totalizers, low-flow cut-off, empty pipe cut-off, flow direction, error system, oper‐
ating time, uni/bidirectional flow, limit switches, pulse output, control for cleaning and batch
Electromagnetic with pulsed constant field
Detection of empty pipe (special cable required in remote
mounted installation)
Depends on sensor size
> 1 x 10 Ω
14
11 to 30 V DC, R = 4.4 KΩ
i
50 ms
I = 2.5 mA, I = 7 mA
DC 11 V DC 30 V
0 to 20 mA or 4 to 20 mA, Alarm
< 800 Ω
0.1 to 30 s, adjustable (for batch: fixed at 0.1 s)
0 to 10 kHz, 50% duty cycle (uni/bidirectional)
DC 24 V, 30 mA, 1 kΩ ≤ R
(power supplied from flowmeter)
DC 3 to 30 V, max. 110 mA, 200 Ω ≤ R
from connected equipment)
0.1 to 30 s, adjustable (for batch: fixed at 0.1 s)
Changeover relay, same as current output
42 V AC/2 A, 24 V DC/1 A
0.4% ± 1 mm/s (for v > 0.1 m/s)
0.2% ± 1 mm/s (for v > 0.1 m/s)
10
≤10 kΩ, short-circuit protected
i
≤10 kΩ (powered
i
67
