...........continued
™
mikroBUS Socket Pin
INT
RX
TX
SCL
SDA
+5V
GND
Info:
1) A 0-ohm resistor has been soldered to connect the VCC_MUX pin to the mikroBUS socket. If an add-on
module cannot handle 5V on this pin, the 0-ohm resistor has to be removed. For more information, see
4.3.3 Hardware
4.4.3 WINC1510 Wi-Fi
Microchip's WINC1510 is a low-power consumption 802.11 b/g/n IoT module, specifically optimized for low-power IoT
applications. The module integrates Power Amplifier (PA), Low-Noise Amplifier (LNA), switch, power management,
and a printed antenna or a micro co-ax (U.FL) connector for an external antenna resulting in a small form factor
(21.7x14.7x2.1 mm) design. It is interoperable with various vendors' 802.11 b/g/n access points. This module
provides SPI ports to interface with a host controller.
WINC1510 provides internal Flash memory as well as multiple peripheral interfaces, including UART and SPI. The
only external clock source needed for WINC1510 is the built-in, high-speed crystal or oscillator (26 MHz). WINC1510
is available in a QFN package or as a certified module.
The communication interface between the ATmega4808 and the WINC1510 Wi-Fi module is SPI, together with some
enable signals and interrupt. The rest of the connections are left unconnected.
Table 4-6. WINC1510 Connections
WIN1510 Pin
4 RESET_N
9 GND
10 SPI_CFG
11 WAKE
12 GND
13 IRQN
15 SPI_MOSI
16 SPI_SSN
17 SPI_MISO
18 SPI_SCK
20 VBAT
©
2020 Microchip Technology Inc.
ATmega4808 Pin
PD6
PC1
PC0
PA3
PA2
—
GND
Modifications.
®
Module
ATmega4808 Pin
PA1
GND
VCC_TARGET
PF4
GND
PF2
PA4
PA7
PA5
PA6
VCC_TARGET
AVR-IoT Wx Hardware User Guide
Function
GPIO
UART1 RX
UART1 TX
TWI0 SCL
TWI0 SDA
1
VCC_MUX , MCP73871
output
Ground
Function
GPIO
Ground
—
GPIO
Ground
ASYNC EXT INT
SPI0 MOSI
SPI0 SS
SPI0 MISO
SPI0 SCK
3.3V supply
User Guide
Hardware User Guide
Shared Functionality
—
—
—
MCP9808 and
ATECC608A
MCP9808 and
ATECC608A
—
—
Shared Functionality
—
—
—
—
—
—
mikroBUS
—
mikroBUS
mikroBUS
—
