H-1200, H-2862
MAIL CART
TOOLS NEEDED
Phillips Screwdriver
Adjustable Wrench
Allen Wrench
(included)
Hardware comes preassembled on the cart. Additional hardware pack also included.
2" Bolt x 4
Axle Rod Stem x 2
Donut Bumper x 2
PAGE 1 OF 6
1-800-295-5510
uline.com
PARTS
1/2" Bolt x 4
Cart Assembly x 1
Upper Basket x 1
5" Swivel Caster x 2
Pour le français, consulter les pages 5-6.
5/16" Nut x 4
1⁄" Bolt x 4
Handle x 1
Para Español, vea páginas 3-4.
1/2" Nut x 8
Collar x 2
Axle x 1
Guide Rod x 3
Lower Basket x 1
10" Rigid Caster x 2
0316 IH-1200
