H-1053, H-1852
H-2059
RUBBERMAID
®
SERVICE CART
TOOLS NEEDED
Phillips Screwdriver
Rubber Mallet
Shelf x 1
(H-2059 x 2)
NOTE: Use rubber mallet for steps 1-5.
1.
Tap caster mounts into openings on underside of base,
then tap casters into caster mounts. (See Figure 1)
Figure 1
Caster
Mount
2. Flip base onto casters. Insert upright into hole on
top of base. Repeat for remaining three openings
on base. (See Figure 2)
Figure 2
PAGE 1 OF 6
1-800-295-5510
uline.com
Top x 1
Base x 1
Caster
Base
Upright
Base
PARTS
Upright x 8
(H-2059 x 12)
Handle x 2
ASSEMBLY
3. Connect underside of shelf to top of each upright.
(See Figure 3)
Figure 3
NOTE: Repeat steps 2-3 for additional shelf
(H-2059).
Para Españwol, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
Screw x 4
Caster Mount x 4
Caster x 4
Shelf
1221 IH-1053

Advertisement

loading
Need help?

Need help?

Do you have a question about the RUBBERMAID H-1053 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for U-Line RUBBERMAID H-1053

  • Page 1 Para Españwol, vea páginas 3-4. Pour le français, consulter les pages 5-6. H-1053, H-1852 1-800-295-5510 H-2059 uline.com RUBBERMAID ® SERVICE CART TOOLS NEEDED Phillips Screwdriver Rubber Mallet PARTS Top x 1 Upright x 8 Screw x 4 (H-2059 x 12) Caster Mount x 4 Shelf x 1 (H-2059 x 2)
  • Page 2 ASSEMBLY CONTINUED 4. Insert handle into top and use screws to secure 5. Connect top to uprights. (See Figure 5) through underside of top. Repeat on opposite side. (See Figure 4) Figure 5 Figure 4 Underside View Handle 1-800-295-5510 uline.com PAGE 2 OF 6 1221 IH-1053...
  • Page 3 H-1053, H-1852 800-295-5510 H-2059 uline.mx RUBBERMAID CARRITO ® DE SERVICIO HERRAMIENTAS NECESARIAS Desarmador de Cruz Mazo de Caucho PARTES 1 Cubierta 8 Postes 4 Tornillos (H-2059 x 12) 4 Soportes 1 Repisa para Ruedas (H-2059 x 2) 1 Base 4 Ruedas 2 Asas ENSAMBLE NOTA: Use un mazo de caucho para los pasos 1-5.
  • Page 4 CONTINUACIÓN DEL ENSAMBLE 4. Inserte el asa en la cubierta y use unos tornillos 5. Conecte la cubierta a los postes. (Vea Diagrama 5) para asegurarla a través del lado inferior de la cubierta. Repita la operación con el lado opuesto. Diagrama 5 (Vea Diagrama 4) Diagrama 4...
  • Page 5: Montage

    H-1053, H-1852 1-800-295-5510 H-2059 uline.ca RUBBERMAID – CHARIOT DE SERVICE OUTILS REQUIS Tournevis cruciforme Maillet en caoutchouc PIÈCES Tablette supérieure x 1 Montant x 8 Vis x 4 (H-2059 x 12) Support de fixation Tablette x 1 pour roulette x 4 (H-2059 x 2) Base x 1 Roulette x 4...
  • Page 6 MONTAGE SUITE 4. Insérez la poignée dans la tablette supérieure et 5. Fixez la tablette supérieure aux montants. utilisez des vis pour sécuriser celle-ci en les insérant (Voir Figure 5) par le dessous de la tablette supérieure. Répétez la procédure sur le côté opposé. (Voir Figure 4) Figure 5 Figure 4 Vue du...
