  • Page 1 User Manual On-Lap M505E/H Monitor...

  • Page 2: Table Of Contents

    Table of Contents Notices, Cautions & Warranty Exclusions —I LCD Pixel Statement —II FCC Statement —II CE Conformity & WEEE Symbol Information —III Chapter 1 Parts of On Lap Monitor & Accessories —1 —1 Section 1 Parts Description —2 Section 2 Accessories Description Chapter 2 Installation Instructions —3 —3...
  • Page 3 —IV —V WEEE —V 日 本 —16 語 —16 —17 —18 —18 1. M505 ® 2. USB Type-C MacBook Pro/Air —19 3. M505H —20 —20 —21 2. USB-A ® —21 3. USB Type-C Nintendo Switch 4. HDMI IN —21 5. HDMI IN —22 6.
  • Page 4 If you need to use this monitor in an abnormal environment such as high temperature, high humidity, confined space, low atmospheric pressure, etc., please contact Gechic customer service center for further advice on usage envi- ronment. 5. Cleaning On-Lap Monitor Unplug the power input before cleaning.

  • Page 5: Lcd Pixel Statement -Ii

    Consult the dealer or an experienced radio/TV technician for help. ■ Caution: 1. Changes or modifications not expressly approved by GeChic Corp. could void the user's authority to operate the equipment. 2. Shielded interface cables and AC power cord, if any, must be used in order to comply with the emission limits.
  • Page 6 CE Declaration of Conformity This product complies with the following standards: EN 55032:2015/AC:2016 Class B(Radio Disturbance requirement of Infor- ■ mation Technology Equipment). EN55024:2010+A1:2015(Immunity requirement of Information Technolo- ■ gy Equipment). EN 61000-3-2:2014 (Harmonic current emissions). ■ EN 61000-3-3:2013 (Voltage fluctuations & flicker) following provisions of ■...

  • Page 7: Section 1 Parts Description

    Chapter 1 Parts of On-Lap Product & Accessories Section 1 Parts Description...

  • Page 8: Section 2 Accessories Description -2

    Section 2 Accessories Description Standard Accessories M505E M505H HDMI-A Video Cable(1.2m) ○ ○ USB Type-C Video Cable(1m) ○ ○ ○ ○ USB-C(female) to USB-A(male) Adapter 65W PD Power Adapter & Power Cord ○ 5V 2A Power Adapter ○ 15-inch Sleeve Bag ○...

  • Page 9: Chapter 2 Installation Instructions -3

    Chapter 2 Installation Instructions Section 1 Setup of M505 Monitor & Use of Sleeve Bag 1. Set up M505 Monitor and Adjust the Angle In the Fig. shown, erect the monitor on the desk. Hold the display by one hand and hold the pull of the I/O base to pull down the I/O base by the other hand.

  • Page 10: Smartphone By Usb Type-C Port

    3. Instructions of Sleeve Bag In the Fig. shown, open the sleeve bag by one hand, hold the screen bezel (don't touch the panel part) by the other hand and put the monitor into the sleeve bag. Warning: When the monitor is in the sleeve bag, please do not put any heavy objects upon the sleeve bag and avoid any collisions, or the monitor may be cracked.

  • Page 11: Section 3 Description Of M505H Proprietary Functions -5

    ○ In OSD menu, select “No” for “Charge from NB/PC" in “Input Source”. Then the smartphone or computer won't power to M505. (After rebooting the monitor, the setting will be reset to “Yes”. You need to enter the OSD page to set again.) ③...

  • Page 12: Usb-A Port Description

    2. USB-A Port Description Connect 65W PD Power Adapter to the DC IN port on the monitor. Insert USB Type-C Video Cable(1.0m) into the USB Type-C ports (DP Alt) on the monitor and computer. And then, connect a mouse or keyboard to the USB-A port on M505H monitor, the signal will be transmitted to the computer or smartphone through the monitor.

  • Page 13: Section 5 Connect To Game Console & Set Up For 2-Player Games

    ○ If the USB port of the computer cannot output sufficient power, please refer to Section 2 to connect 5V 2A power Adapter to the DC IN port on the M505E . (For M505H, please refer to Section 3 to connect the 65W PD Power Adapter. ) Powered by USB-C port of the PC Powered by USB-A port...

  • Page 14: Section 6 Use Of Hdmi Out Port -8

    Section 6 Use the HDMI OUT Port Notice 1: As the image is input by HDMI IN port, the HDMI OUT port can output the same image. The HDMI OUT port can't output the image from USB Type-C port. Notice 2: While using HDMI OUT ports to connect multiple monitors, all the moni- tors are able to display the same image only, not different images.

  • Page 15: Section 7 Connect To Headphone Or Speaker -9

    3. Connect to Live Broadcaster Please follow the steps below for connection. ○ HDMI-A to mini-HDMI Video Cable(Optional) to connect a camera or video recorder to the HDMI IN port on M505 monitor. ○ HDMI-A Video Cable(1.2m) to connect live broadcaster to the HDMI OUT port on M505 monitor.

  • Page 16: Section 8 Installation Of Vesa 100 Arm Or Wall Mount -10

    Section 8 Installation of VESA 100 Arm or Wall Mount Please follow the steps below for setup. ○ Screw the M505 VESA 100 bracket (Optional) to the I/O base of the monitor by 4 M4 screws. ○ Clip the monitor screen and VESA 100 aluminum alloy bracket together by the two clips to prevent the screen from falling down.

  • Page 17: Section 2 Osd Menu Description -11

    Power Press Power Button to power on/off the Monitor. Press this button to show "Input Source" and then press Input Source/Exit switch the input sources. When using the OSD menu, press this button to return to previous page. Press this button to launch OSD panel. In OSD panel, press this Menu/Select button to select and enter the next page.
  • Page 18 2) Overscan: only available when HDMI video signal input(ex:1080P/720P). Enabling this function allows you to calibrate the display area. 4. OSD Menu 1) Language Select: Change to the other language. 2) H. Position: Move the OSD menu left/right. 3) V. Position: Move the OSD menu up/down 4) OSD Timer (sec): Adjust the idle time before OSD menu disappears.

  • Page 19: Section 2 Settings Of Extended Display On Mac (Os

    "1080p" for On-Lap M505. For vertical display, select 270ﾟ at "Rotation" Chapter 5 Product Specification Section 1 General Specification Item On-Lap M505E On-Lap M505H Panel Wide screen 15.6-inch (16:9) True Resolution 1920x1080 Color Depth 16.7M Colors 16.7M Colors...

  • Page 20: Section 2 Supported Operating Modes -14

    Item On-Lap M505E On-Lap M505H USB-C Power Delivery Support HDCP Support HDCP CEC Support ≦ 10W Power Consumption Power Consumption- Standby Mode <0.5W <0.5W Power Consumption- Off Mode Rated Voltage 2.0A(Typ.) Operation: 0~50 ℃ ; Storage :-20~60 ℃ Environment Conditions Display top cover: 364mm*250mm*6.9mm...

  • Page 21: Section 3 Supported Video Modes -15

    Sleep mode> and select “Disable” for Wake When AC Adapter is Disconnected” so that Switch® won't wake from sleep mode when AC adapter is discon- nected. GeChic Corporation 11F-3, No. 138, Zhongming S. Rd., West Dist., Taichung, Taiwan Customer Service: service@gechic.com...
  • Page 23 こ の 装 置 は 、 ク レ ス B 機 器 で す 。 こ の 装 置 は 、 住 宅 環 境 で 使 用 す る こ と を 目 的 と し て い ま す が 、 こ の 装 置 が ラ ジ オ や テ レ ビ ジ ョ ン 受 信 機 に 近 接 し て 使 用 さ れ る と 、 受 信 障 害 を...
  • Page 25 ○ ○ ○ ○ ○ ○ ○ ○ ○ ○...
  • Page 27 ■ ■ ○ ○ ○...
  • Page 28 ③ ○ ○...
  • Page 29 ○ ○ ○...
  • Page 30 ○ ○ 、 注意： 次...
  • Page 31 ○ ○ ○ 以下 ○ ○ ○...
  • Page 32 以下 ○ ○ ○ （ （ 下 ：...
  • Page 33 ○ ○ ○...
  • Page 34 「 「...
  • Page 37 ≦ < < R53848 RoHS...
  • Page 39 GeChic Corporation 11F-3, No. 138, Zhongming S. Rd., West Dist., Taichung, Taiwan Customer Service ： service@gechic.com Rev. 2020/9/3...
  • Page 40 保証規定 １年 保証 (販売店のスタンプ)
