- Page 1 T1 Series Touch Monitor User Manual How-to Videos V1. 2021/11/05...
-
Page 2: Table Of Contents
Content —1 Notices, Cautions & Warranty Exclusions —2 Chapter 1 Parts of the Monitor & Accessories —2 Section 1 Monitor Description —3 Section 2 Accessories Description —4 Chapter 2 Installation Instructions —4 Section 1 Connect to Power Adapter and USB Signal& Video Cables —5 Section 2 Use T1S1 Stand —8... -
Page 3: Notices, Cautions & Warranty Exclusions -1
If you need to use this monitor in an abnormal environ- ment such as high temperature, high humidity, confined space, low atmospher- ic pressure, etc., please contact Gechic customer service center for further advice on operating environment. -
Page 4: Chapter 1 Parts Of The Monitor & Accessories -2
Chapter 1 Parts of the Monitor & Accessories Section 1 Monitor Description 1. LED Power Indicator Instruction It shows green light when the monitor is "On" and shows red light when the moni- tor is stands by. There is no light when the monitor is "Off". -
Page 5: Section 2 Accessories Description -3
12V-2A AC-DC Power Adapter x1 USB-A to USB-C Power& Touch Signal Cable (1.5m) x1 Warning! This adapter USB Type-C Video Cable (1m) x1 is used for T1 Series monitor only. Please DO NOT connect it to other products. Wall Mount Bracket x1... -
Page 6: Chapter 2 Installation Instructions -4
Optional Accessories Description Connect one end to computer's USB-C (DP Alt) USB Type-C Video Cable port, and the other end to T1's USB-C port to deliv- (2m) er audio, video, power and touch signals at the same time. USB-A (male) to USB-A It is used to connect the "USB-A to USB-C power (female) Extension Cable and touch cable."... -
Page 7: Section 2 Use T1S1 Stand -5
As shown in the fig., connect the USB-C video cable to the USB Type-C(DP Alt) Port (Thunderbolt 3 port) on the computer. The computer outputs video, USB signals, 5V current through this cable to the monitor. There is no need to connect to the adapter when the computer's USB-C port can supply 1.6A current. - Page 8 1. Instructions to Assemble the Stand: Monitor Tilt Angle at 155 Degrees Monitor Model: T111A Monitor Model: T151A/ T131A ○ ○ ○ ○ As shown in fig., use the Screw A As shown in the fig., use the Screw to fix the metal plate stand to two A to fix the metal base plates to both sides of the wall mount bracket.
- Page 9 2. Instructions to Assemble the Stand: Monitor Tilt Angle at 110 Degrees Monitor Model: T111A Monitor Model: T151A/ T131A ○ ○ ○ ○ As shown in fig., use the Screw A As shown in the fig., use the Screw to fix the metal plate stand to two A to fix the metal base plates to both sides of the wall mount bracket.
-
Page 10: Section 3 Use Wall Mount Bracket -8
8 Section 3 Use Wall Mount Bracket Step 1 Please select suitable screws according to the ○ wall material. As shown in the fig., mount the wall mount bracket on the wall (the screw is not included in the monitor package; please ensure the screw can suspend more than 2 kg before fixing the monitor). -
Page 11: Section 5 Connect To Mouse, Speaker, Wireless Display Adapter With
90 degrees 0 degrees Landscape Display Portrait Display Downward Viewing Rotate the monitor to portrait display T1S2 supports 360-degree rotation. If you need to rotate it to 90 degrees, please tilt the monitor to 180 degrees first, rotate it to portrait mode, and tilt back to the viewing angle. - Page 12 1. Connect to mouse, microphone, camera, etc. 2. Connect to speakers (USB-A for power supply, headphone jack to output sound) 3. Connect to Wireless Display Adapter (HDMI port) Use USB-A port on T1 monitor to power HDMI Wireless Display Adapter.
-
Page 13: Chapter 3 Power Supply And Power On/Off The Monitor -11
Chapter 3 Power Supply and Power On/Off the Monitor Section 1 12V and 5V Current Input The T1 monitor supports the following two charging methods. 1. Input 12V current via DC IN port (5V current is not allowed): Connect the 12V power supply to DC IN port, the monitor will automatically interrupt the current from USB-C port, and take the current from DC IN port only. -
Page 14: Chapter 4 Osd Menu Description -12
Chapter 4 OSD Menu Description 1. Display Settings As shown in the Fig., enter "Display Settings" to adjust "Brightness", "Contrast", "Sharpness", etc. 1) ECO Mode: The maximum brightness is at 50 in ECO Mode. 2) Auto Adjust: Launch "Auto Contrast Adjust" and "Auto Brightness Adjust"... -
Page 15: Chapter 5 Touch Monitor Settings And Precautions -13
Linux, Ubuntu or Chrome OS, please consult your com- puter manufacturer whether the computer is enabled to support " Microsoft Multi -touch protocol". If the protocol is supported, you can use T1 series touch moni- tor. -
Page 16: Section 2 Not To Turn Off The Power Of Usb Device Automatically On Windows 11
Operation System External Touch Monitor Support (via USB port) Apple Mac OS Not supported (e.g., Apple iMac, MacBook series ® computers) Apple iOS Not supported (e.g., Apple , iPhone series ® smartphone) Windows11/ Supported Windows10/Windows7 Windows Embedded Supported Standard 7(SKU-P) WinCE 6.0/ WinCE 7.0/ Not Supported Windows XP... - Page 17 Click “Power Management” and disable “Allow the computer to turn off this device to save power”, and then click “OK”. Section3 Multi-Monitor and Touch Monitor Settings(Windows 11/ 10/ 7) 1. Touch Monitor Settings in Windows 11/ 10/ 7 If the computer does not activate touchscreen function automatically or the moni- tor doesn’t sense touch position accurately, please use "Tablet PC Settings"...
-
Page 18: Section 4 Touch With Stylus, Hand Gloves And Wet Fingers -16
Section 4 Touch with Stylus, Hand Gloves and Wet Fingers 1. Use the touch Stylus T1 series touch monitor does not support the proprietary active styluses of other tablet PCs or smartphones. ˙ Passive Touch Stylus: T1 series touch monitor supports passive touch pens with conductive rubber tip or plastic disc larger than 6mm in diameter. -
Page 19: Chapter 6 Product Specification -17
Environment Conditions Operation: 0~50°C/ Storage: -20~60°C Weight of Monitor 1200g 840g 780g (Typical) Weight of T1S2 434g Country of Origin Made in Taiwan Certifications R53848 RoHS To request the drawing of the monitor's dimension and product EOL notifications, please write to : service@gechic.com... - Page 20 Monitor Dimension T15A T131A T111A...
- Page 21 Dimension of the Monitor with T1S2 Stand T15A and T1S2 Stand at 110° Stand at 115° T131A and T1S2 Stand at 110° Stand at 115° T111A and T1S2 Stand at 110° Stand at 115°...
-
Page 22: Section 2 Supported Display Modes -20
Section 2 Supported Display Modes Horizontal Frequency (kHz) Vertical Frequency (Hz) Resolution Refresh Rate 640x480 60Hz 31.469 59.940 720x480 60Hz 29.855 59.710 800x600 60Hz 37.879 60.317 848x480 60Hz 31.02 60.000 960x600 60Hz 37.212 59.635 1024x768 60Hz 48.363 60.004 1152x864 60Hz 53.783 59.959 1280x600... -
Page 23: Chapter 7 Troubleshooting -21
Chapter 7 Troubleshooting Problem Solution The computer is connected with Please refer to Chapter 5 > Section 3. Open "Tablet PC multiple monitors. When touch- Settings" in Windows "Control Panel” to start touch monitor ing T1 monitor, the cursor ap- settings. - Page 24 Consult the dealer or an experienced radio/TV technician for help. Caution: Changes or modifications not expressly approved by GeChic Corp. could void the user's authority to operate the equipment. 2. Shielded interface cables and AC power cord, if any, must be used in order to comply with the emission limits.
