  • Page 2: Table Of Contents

    Section 2 Accessories Description —3 Chapter 2 Installation Instructions —5 Section 1 Set up and Put away On-Lap 2101H Section 2 Use USB Type-C Port to Connect to MacBook or Other —5 —5 Section 3 Use USB Type-C Port to Connect to Smartphone —6...
  • Page 3 目次 —IV —V 日 —V 本 語 —13 —13 —14 —15 —15 —17 —17 —18 —19 —20 —20 —21 —21 —21 LED OSD —21 2. OSD —24 —24 —25 —26 —26...

  • Page 4: Notices, Cautions & Warranty Exclusions

    If you need to use this monitor in an abnormal environment such as high tempera- ture, high humidity, confined space, low atmospheric pressure, etc., please contact Gechic customer service center for further advice on usage environ- ment.

  • Page 5: Lcd Pixel Statement -Ii

    Please read the warranty terms below carefully, and follow the usage guide and precautionary notes. Please keep this manual for future reference. GeChic does not warrant uninterrupted or error-free operation of this Prod- uct. The warranty only covers failure /malfunction under normal use condi- tions during warranty period.
  • Page 6 Consult the dealer or an experienced radio/TV technician for help. Caution: Changes or modifications not expressly approved by GeChic Corp. could void the user's authority to operate the equipment. Shielded interface cables and AC power cord, if any, must be used in order to comply with the emission limits.

  • Page 7: Chapter 1 Parts Of On Lap Product & Accessories -1

    Chapter 1 Parts of On Lap Product & Accessories Section 1 Parts Description Front Back Input & Output Ports...

  • Page 8: Section 2 Accessories Description -2

    Section 2 Accessories Description Power Cord AC/DC Power Supply Adapter(19V-4.6A) HDMI-A Video Cable (1.5m) USB Type-C Video Cable (1.0m) Monitor Carrying Bag (21A1)

  • Page 9: Chapter 2 Installation Instructions -3

    Chapter 2 Installation Instructions Section 1 Set up and Put away On-Lap 2101H (1)Please follow the steps below to set up the On-Lap2101H monitor. ◆ Step 1 ◆ As shown below, pull out the magnetic buckle, erect the I/O Base, and fit the tenon on the magnet buckle into the slot.
  • Page 10 67 degrees. 73 degrees. (2) Please follow the steps below to put the On-Lap 2101H monitor into the monitor carrying bag (21A1). ◆ Step 1 ◆ Turn off the monitor and unplug all the cables.

  • Page 11: Section 3 Use Usb Type-C Port To Connect To Smartphone -5

    And the USB Type-C port on the PC must support USB PD power input to receive the output current from the monitor. Please power on the PC and the On-Lap 2101H first, as shown below, connect the USB Type-C video cable to the On-Lap 2101H and the PC.

  • Page 12: Section 4 Connect To Nintendo Switch® -6

    Switch® will not output images. 1. Use USB Type-C port to connect to Nintendo Switch® Console As shown on the right, please turn on the Nintendo Switch® and On-Lap 2101H firstly, and then connect the USB Type-C video cable to the On-Lap 2101H and Nintendo Switch®...

  • Page 13: Section 6 Use Usb-A Or Usb Type-C Port To Power The Monitor -7

    Lap 2101H. ◆ Note: If the current required by the computer stick is greater than 5V 2.4A, then the USB-A port on the On-Lap 2101H cannot be used to power it. Please use other 5V charger to power the computer stick.

  • Page 14: Section 8 Instruction For Connecting To Headphones Or Speakers -8

    Section 8 Instruction for Connecting to Headphones or Speakers Please insert the 3.5mm plug of the earphone into the headphone out on the monitor’s base. If a microphone is inserted into the headphone jack, the monitor cannot output audio. The monitor contains a pair of 2.0W speakers, which supports dual-channel audio. Please set the sound setting of the game console or DVD player to dual-channel output.
  • Page 15 2. Color Settings 1) Color Effect: If the PC image output format is RGB Limited, it is recommended to select "Standard 1"; if it is RGB Full format, it is recommended to select "Standard 2". Select "Phone" mode to make the colors more vivid;...

  • Page 16: Chapter 4 Product Specification -10

    7. Information: Show Frequency of the input image, On-Lap model name, firmware version, etc. 1) Reset: Select "Yes" to reset to defaults. Chapter 4 Product Specification Section 1 General Specification On-Lap 2101H Item Panel Wide screen 21.5” (16:9) True Resolution...

  • Page 17: Section 2 Supported Operating Modes -11

    Section 2 Supported Operating Modes Horizontal Frequency (kHz) Vertical Frequency (Hz) Resolution Refresh Rate 640x480 60Hz 31.469 59.940 720x480 60Hz 29.855 59.710 800x600 60Hz 37.879 60.317 848x480 60Hz 31.02 60.000 960x600 60Hz 37.212 59.635 1024x768 60Hz 48.363 60.004 1152x864 60Hz 53.783 59.959 1280x600...

  • Page 18: Chapter 5 Troubleshooting

    Please check the table of HDMI format supported by 2101H. If the input source exceeds the resolution and frequency supported by 2101H monitor, the images cannot be displayed properly. GeChic Corporation 11F-3, No. 138, Zhongming S. Rd., West Dist., Taichung, Taiwan Customer Service: service@gechic.com...
  • Page 19 21A1) USB-A USB Type C Nintendo Switch® 5 35 45 85 Gechic...
  • Page 20 99.99 0.01 WEEE Rear Dock VCCI-B...
  • Page 23 On-Lap2101H On-Lap2101H USB Type-C HDMI...
  • Page 24 On-Lap2101H 21A1)
  • Page 25 1.PC Type-C DisplayPort DP Alt) USB PD USB Type-C DisplayPort DP Alt Mode) USB Type-C USB PD USB Type-C On-Lap 2101H USB Type-C -Lap 2101H USB-A USB 2.0) USB Type-C USB-A USB Type-C USB-A 5V 2A 2. PC Type-C DisplayPort Alt Mode (DP Alt)
  • Page 26 2101H USB-A USB 2.0) Power Output to PC PC Power Output to PC PC Switch 1.USB Type-C Nintendo Switch® Nintendo Switch® On-Lap 2101 USB Type-C On-Lap 2101H Nintendo Switch® Switch® Switch USB Type-C Switch Switch Switch 2101H 2101H Switch Switch SWITCH 2.
  • Page 27 21A1) Nintendo Switch® 2101H USB Type C Switch Joy-con Nintendo Switch® Nintendo Switch® HDMI-A 2101H HDMI...
  • Page 28 1. USB-A A.USB Type-C USB-A Type-C On-Lap 2101H Lap 2101H On-Lap 2101H B.USB Type-C USB-A 5V 2.0A 5V 2A 9V 2A 15V 2A 20V 2.25A Intel® Compute Stick HDMI-A On-Lap 2101H USB-A USB Type-C V-2A On-Lap 2101H 5V 2.4A On-Lap 2101H USB-A Microsoft®...
  • Page 29 3.5mm Headphone Out) 2.0W 5.1ch 1. LED On-Lap 「 「 On-Lap Language Select Language Select...
  • Page 32 On-Lap 2101H ワイドスクリーン 万色 HDMI-A, USB Type-C 出力 3.5mm mini jack) 2W(Max) x2 < < 4.62A 500mA (USB Type-C USB-A Max.) 2.4A (USB Type-C 2A/ 9V 2A/ 15V 2A/ 20V 2.25A USB-C Max.) 90%RH( 90% RH( W/H/T) 489mm*326mm*7.5mm~33.8mm( 2,348g R53848...
  • Page 33 640x480 60Hz 31.469 59.940 720x480 60Hz 29.855 59.710 800x600 60Hz 37.879 60.317 848x480 60Hz 31.02 60.000 960x600 60Hz 37.212 59.635 1024x768 60Hz 48.363 60.004 1152x864 60Hz 53.783 59.959 1280x600 60Hz 37.377 59.900 1280x720 50Hz 37.500 50.000 60Hz 45.000 60.000 1280x720 60Hz 44.772 59.855...
  • Page 34 1920x1080P 50Hz/59.94Hz/60Hz 1280x720P 50Hz/59.94Hz/60Hz 720x480P 59.94/60Hz 640x480P 59.94/60Hz 一 「...
  • Page 35 GeChic Corporation 11F-3, No. 138, Zhongming S. Rd., West Dist., Taichung, Taiwan Customer Service ： service@gechic.com Rev. 2020/2/19...
  • Page 36 保証規定...
