Matrix System ®

• Sample Home Audio System

This System is designed to demonstrate a variety of Home Entertainment products. The Source Chain
includes A/V and stereo audio components. Each component can be demonstrated through any
combination of speakers in the System.
Receivers in the System may include those with surround sound capability, thus allowing basic Home
Theater demonstration.
Audio for VCRs, laser disc players, etc. is routed through the same set of Switching Chains as the stereo
audio sources and plays to the same receivers and speakers. Video signals from all components are routed to
a single big screen monitor or projection system.
System Component Mix
8 Audio Sources (L)
16 Receivers with preamp input,
speaker-level outputs (L/H)
8 Speaker Pairs (H)
MVP Control Panel:
Switching Requirements
1 1210 Relay Module
2 1310 Relay Modules
1 1410 Switching Module
1 MVP Control Module
2 MVP Dual Chain Modules
1 10" Shelf Mount Frame
1 MVP Power Supply
