Descriptions

MVP Sound Pressure Meter, Side View

A. Microphone Input Jack –
the microphone which supplies the
MVP-SP with the demonstration
area sound level plugs in here.
See Installation Section for
information on proper
positioning of the microphone.
B. Sound Pressure Output
Connector – connects the
output of the MVP-SP to the
MVP Speaker Equalizer (see
below).
C. Parallel Power Connectors –
like Parallel Power Connectors
on Dual Chain Modules. (see
page 25)
30
3 "
A
B
C
Figure 13 – MVP Sound Pressure
Meter, Side View
1
/
2
