MTI Connect Hub Product Manual

MOUNTING
NOTE: This device is for commercial use only. It is not intended or suitable for any consumer applications.
1
NOTE: This device requires professional installation to prevent tampering with or removal/replacement of the
antenna by anyone other than qualified service professionals.
2
Install the power supply and power up the Hub. Secure the power supply by wrapping the rubber flap around the connector
and attaching into the opening on top of the Hub.
3
If using with MTI Connect application software, plug the Hub into the internet with an available Ethernet cable or setup with
WIFI credentials. If not using with MTI Connect, move on to Freedom Micro Provisioning.
www.mtigs.com | T:800.426.6844
CONNECT HUB PRODUCT MANUAL
OR
Main Plug of the adapter acts as disconnect
device, the socket-outlet shall be installed near
the equipment and shall be easily accessible.
Warning: The Adapter used must be marked with "LPS"
or "Limited Power Sources"; otherwise those others are
prohibited to use.
La prise principale de l'adaptateur agit comme
un dispositif de déconnexion, la prise de
courant doit être installée près de l'équipement
et doit être facilement accessible.
Avertissement: L'adaptateur utilisé doit porter la
mention «LPS» ou «Sources d'alimentation limitées».
sinon, ces autres sont interdits d'utilisation.
MTI P/N 063-00210 rev D ©2019 MTI All Rights Reserved
1
