Matrix System ® • Sample Home Theater System
This System creates a full Home Theater demonstration, including laser disc players, hi-fi stereo VCRs and up
to 8 surround receivers. The receivers can deliver speaker level output to front, rear, and center channel,
plus low-level output to powered subwoofer speakers.
Video signals are all routed to a single big screen monitor or projection system. All audio source outputs are
routed into the complete Surround Sound audio system.
Several of the relay modules included in this system are OnSite Modules, are are used to enhance the DVD
capabilities of the system.
System Component Mix
8 A/V Sources (digital, stereo and composite video) (DLV)
1 Monitor (V)
8 Pro-logic receivers with digital and preamp inputs;
composite video input and output; front, rear
and center-channel speaker-level outputs and
preamp sub outputs (DLV/VHHHL)
8 Front Speaker Pairs (H)
8 Rear Speaker Pairs (H)
8 Center-channel Speakers (H)
8 Amplified Subwoofer Speakers (L)
MVP Control Panel:
Switching Requirements
1 1320 Relay Module
2 4000 Logic Modules
2 4005R Relay Modules
dedicated no switching needed
3 1310 Relay Modules
2 4000 Logic Modules
2 4005T Relay Modules
1 1410 Relay Module
1 1410 Relay Module
1 1410 Relay Module
1 1210 Relay Module
1 MVP Control Module
3 MVP Dual Chain Modules
1 MVP Remote Control
1 12" Shelf Mount Frame
1 MVP Power Supply
