Matrix System • Sample Autosound System II
This configuration creates a small but versatile system for the demonstration of virtually any Autosound
product combination – ranging from a simple head unit and pair of full-range speakers to a full tri-amp
configuration with front and rear speaker pairs and separate subwoofers with their own dedicated
amplifiers.
By incorporating a dedicated crossover/passive equalizer into the low-level bus, the 2-Channel low-level
output of the head units can be separated and routed to front, read and dedicated subwoofer amplifiers
and front, rear and subwoofer speakers.
System Component Mix
16 Head Units (HL)
7 Front Amplifiers (L/H)
7 Rear Amplifiers (L/H)
16 Front Speaker Pairs (H)
8 Rear Speaker Pairs (H)
8 Subwoofers (L/Hc - requires dedicated Sub Amplifier)
MVP Control Panel:
*
one component chain remains available for future use
Switching Requirements
2 1312 Switching Modules
1 1312 Switching Module
1 1312 Switching Module
2 1410 Switching Modules
1 1410 Switching Module
1 1442 Switching Module
1 MVP Control Module
3* MVP Dual Chain Modules
1 12" Flush Mount Frame
1 MVP Power Supply
