Matrix System • Sample Autosound System III
Autosound System III offers versatility for switching amplifiers and processors, as well as a large head unit
capacity. Front-to-rear fading can be demonstrated with or without amplifiers. Pre-amplifier level equalizers
or active crossovers can be used with virtually any combination of components, allowing the system to
demonstrate both full-range and "separates" speakers.
Note: By Y-ing the low level input, the high level output and the trigger wire of the amplifiers, each
amplifier can be selected to output to front, rear and/or subwoofer speakers.
System Component Mix
24 Head Units (HHL)
3 Low Level Processors (L/LLL)
7 F Amplifiers (L/H)
7 R Amplifiers (L/H)
8 S Amplifiers (L/Hc)
16 Front Speaker Pairs (H)
8 Rear Speaker Pairs (H)
8 Subwoofers (Hc)
MVP Control Panel:
Switching Requirements
3 1312 Switching Modules
3 1410 Switching Modules
1 1242 Switching Module
1 1312 Switching Module
1 1312 Switching Module
1 1210 Switching Module
1 1442 Switching Module
2 1410 Switching Modules
1 1410 Switching Module
1 1440 Switching Module
1 MVP Control Module
4 MVP Dual Chain Modules
1 14" Flush Mount Frame
1 MVP Power Supply
