  • Page 2 Sixth Edition, April 2004, SME-1-100(F) (out of print) Seventh Edition, September 2004, SME-1-100(G) All Rights Reserved, Copyright © 1998, 2004, Hitachi, Ltd. The contents of this publication may be revised without prior notice. No part of this publication may be reproduced in any form or by any means without permission in writing from the publisher.
  • Page 3 SAFETY PRECAUTIONS Be sure to read this manual and all other attached documents carefully before installing, operating inspecting or conducting maintenance on this unit. Always use this unit properly. Be sure to carefully read the information about the device, the safety information and precautions before using this unit.
  • Page 4 DANGER Form emergency shutdown circuits, interlock circuits or the like outside the programmable controller. Failures in the programmable controller may result in damage to the equipment or accidents. Use the I/O current with any I/O module within the maximum allowable limit. Overcurrent flow can cause damage to the parts, resulting in accidents, fires, or failures.
  • Page 5 CAUTION To prevent possible failures, house the programmable controller in a drip-proof enclosure in cases where it is feared to be wetted with water. See Chapter 1 on page 3. Even if the input voltage of the power supply module falls within a specified range, assume it to be in an input power abnormality when it is close to the upper or lower limit of the range, and call upon the power supply facility manager for a checkup.
  • Page 6 CAUTION Dust deposited on the connector can result in degraded contact. Install and wire the equipment immediately upon unpacking. Modules are susceptible to damage. Note the following points when installing or removing modules. • Check that the connectors are free from bent or broken pins and the pins are aligned straight and are free from dust.
  • Page 7 PROHIBITION Do not install, wire, handle, or remake the programmable controller beyond such an extent as may be defined in this manual. We will not be liable for any damages to our programmable controller and ancillary equipment and for physical injury arising out of such actions. See Chapter 1 on page 9.
  • Page 8 REQUIREMENT Attach a fuse or circuit protector to the external power supply to protect against short circuits. Use a circuit protector matching the rating of the power supply. Verify the wiring before turning on the programmable controller. Do not shut down (turn off or reset) the programmable controller without making sure that the peripheral equipment is off or will be unaffected by the shutdown of the programmable controller.
  • Page 9 REQUIREMENT Excessive accumulation of heat in the enclosure may cause a fire or hardware failure. When the ambient temperature reaches 48°C or higher, the maximum output current of the power supply module is limited. At 55°C, for instance, it is limited to 5.85 A. Where this is very likely, install a cooling fan in the enclosure or reduce the number of modules installed therein.
  • Page 10 Notes for using Windows PC software The Windows® PC (tool) software works with both S10mini and S10/2α Series. The user should note the following points: For the PC software that can be used on the S10mini, see the next page titled “Controller Models and Compatible Software Packages.”...
  • Page 11 4. Analog or pulse counter module loading (LQA000, LQA100, LQA200, LQA500, LQA600, or LQC000) -- No such loading required Since the S10mini controller contains system programs for the analog modules and pulse counter module in flash memory within the CPU module, loading of the system programs is not required (loading of the various settings, however, is required).
  • Page 12 Controller Models and Compatible Software Packages Usable PCs controller models • HITACHI S10/2α, 2αE, 2αH, and 2αHf • HITACHI S10/4α, 4αF, and 4αH • S10mini models S, H, F, and D PCs models and compatible software packages Software packages that can run on particular PCs models are listed below.
  • Page 13 Hitachi Engineering Service Co., Ltd. The malfunctioning part will be replaced or repaired free of charge. If the malfunctioning is shipped, however, the shipment charge and packaging expenses must be paid for by the customer.
  • Page 14 THIS PAGE INTENTIONALLY LEFT BLANK.
  • Page 15 PREFACE Thank you for your purchasing of Hitachi’s programmable controller, S10mini. This manual explains how to handle basic component modules of the S10mini, such as CPUs, power supplies, mount bases, memory modules, etc. For information on I/O and option modules and associated software, refer to the relevant manuals or user’s guides.

  • Page 16: Table Of Contents

    CONTENTS 1 BEFORE USE ........................2 OVERVIEW........................2.1 Outline of the System ....................... 2.2 Module Configuration in the CPU Unit ................2.3 Module Configuration in the I/O Unit................3 NAMES AND FUNCTIONS OF PARTS ................3.1 CPU Module........................3.2 Remote I/O Station Module....................3.3 Extension Memory Module ....................
  • Page 17 6 SETTINGS .......................... 51 6.1 Outline of I/O Number Settings ..................52 6.2 Configuration and Assignment Range of I/O Numbers............ 53 6.3 Setting I/O Numbers ......................54 6.3.1 Setting the mounting status of PI/O modules............55 6.3.2 Setting partition status (FREE/FIX) ................56 6.3.3 Setting the number of I/O points ................
  • Page 18 8.4.5 Clock precision ......................8.5 Conditions of the I/O Input/Output Registers and Internal Registers in Case of Errors... 8.6 Restrictions on Mounting Option Modules ..............8.7 Output Current of the Power Supply Module..............8.8 Memory Backup ....................... 8.9 Output Timing of the PCs OK Signal................9 MAINTENANCE........................

  • Page 19: Before Use

    1 BEFORE USE...
  • Page 20 1 BEFORE USE Connecting the battery The backup battery contained in the CPU module is left unconnected during shipment to prolong its useful life. Before using the CPU module, connect the battery by performing the following procedure: ① Before handling the CPU module, ground yourself to discharge any static electricity. ②...
  • Page 21 1 BEFORE USE NOTICE A loose connector may be disconnected easily. If it is disconnected during operation, backup data may be lost. To avoid this, push the connector sufficiently into the plug on the PC board until it snaps into place. Battery connector CPU module Lock arm...
  • Page 22 1 BEFORE USE Use the programmable controller within the allowable limits of environmental conditions specified below. Use in a room-temperature, room-humidity environment (15 to 35°C, 45 to 85%RH) is recommended to assure extended periods of normal operation. Use in a high-temperature, high- humidity environment where sharp temperature changes are experienced within one day may detract from the product’s useful life.
  • Page 23 1 BEFORE USE Mounting modules When you mount I/O or option modules in the CPU or I/O unit, follow the following instructions to avoid noise interference from connections external to the I/O unit: Do not mount an I/O module rated at 100 VAC/VDC or higher in the slot next to the CPU module, but mount it as remote from the CPU module as possible.
  • Page 24 1 BEFORE USE Output module Attach a fuse to the load power supply of the output module for protecting against short circuits. Use a fuse matching the rating of the load. If a fuse in excess of the rating is used, short circuits in the load could burn the PC board, casing and other components.
  • Page 25 Internal replacement parts The user should not replace any internal part other than those described in the manual. If such a part fails, replace the module in its entirety. When replacing parts, ask a Hitachi maintenance person. Inserting and removing modules Be sure to turn off the power switch before plugging modules in or out to avoid failures and electrical shock hazards.
  • Page 26 1 BEFORE USE Grounding * Check the wiring made for grounding. Is the ground line shared with other units? • Is the grounding point of the S10mini controller separated from that of a power distribution • panel by at least 15 m? * Make sure that signal cables such as remote I/O cables are well apart from the power cables.
  • Page 27 1 BEFORE USE PROHIBITION Do not install, wire, handle, or remake the programmable controller beyond such an extent as may be defined in this manual. We will not be liable for any damages to our programmable controller and ancillary equipment and for physical injury arising out of such actions.
  • Page 28 THIS PAGE INTENTIONALLY LEFT BLANK.

  • Page 29: Overview

    2 OVERVIEW...

  • Page 30: Outline Of The System

    2 OVERVIEW 2.1 Outline of the System The optional modules (ET.NET, OD.RING, and J.NET) for a network and communication modules for the I/O unit (RI/O and JST) are arranged as shown below. 10BASE-5 (Up to 1024 stations can be connected.) 10BASE-T Host S10mini...
  • Page 31 2 OVERVIEW Compact, space saving Compact, space saving - takes up only one half of the space requirement of the S10/2α when mounted. Standard real-time, multitasking operating system -- Compact PMS The S10mini controller comes standard with the Compact PMS, which is a full-scale, real-time, multitasking operating system.

  • Page 32: Module Configuration In The Cpu Unit

    D.INPUT LQX100 D.INPUT LQX100 D.INPUT LQV000 LQP000 LADDER Example combination of modules STOP MODE POWER SIMU NORM PROTECT RESET HITACHI S10mini 100-120VAC 100-120VAC 100-120VAC 100-120VAC 100-120VAC 100-120VAC 100-120VAC 100-120VAC DC5V SERVICE CHECK POWER AC100-120V Mounted on an 8-slot mount base...

  • Page 33: Module Configuration In The I/O Unit

    2 OVERVIEW 2.3 Module Configuration in the I/O Unit LQV000 LQS000 RI/O LQX100 D.INPUT LQX100 D.INPUT R/IO POWER STND HITACHI HSC-1000 100-120VAC 100-120VAC DC5V SERVICE CHECK Example combination of modules POWER AC100-120V Mounted on a 2-slot mount base Required modules...
  • Page 34 THIS PAGE INTENTIONALLY LEFT BLANK.

  • Page 35: Names And Functions Of Parts

    3 NAMES AND FUNCTIONS OF PARTS...

  • Page 36: Cpu Module

    LADDER LADDER STOP STOP MODE MODE SIMU NORM SIMU CPU RUN NORM CPU RUN PROTECT PROTECT RESET RESET HITACHI   S10mini HITACHI   S10mini CPU modules RI/O CPU model Type Built-in memory capacity STOP Model S LQP000 None STOP/ Model H LQP010 1 MB...
  • Page 37 3 NAMES AND FUNCTIONS OF PARTS Name Function Ladder program execution switch Starts or stops the execution of the ladder program ---- ① LADDER • RUN: Executes the ladder program. RUN/STOP • STOP: Stops the ladder program. Mode switch Sets the mode of operation for running a ladder program. ②...

  • Page 38: Remote I/O Station Module

    3 NAMES AND FUNCTIONS OF PARTS 3.2 Remote I/O Station Module LQS000 LQS000 RI/O RI/O RI/O RI/O ST.NO ST.NO HITACHI HSC-1000 HITACHI HSC-1000 128M HOLD RI/O1 RI/O2 RI/O1 RI/O2 150Q 100Q Signals on the terminal block - 20 -...
  • Page 39 3 NAMES AND FUNCTIONS OF PARTS Name Function Station number setting switches Each sets a station number. Set the first two digits of the I/O number as follows: ① higher-order digit using the U-switch and low-order digit using the L-switch. Input/output point count setting Selects the number of input/output points occupied by one slot on the mount base (16, ②...

  • Page 40: Extension Memory Module

    3 NAMES AND FUNCTIONS OF PARTS 3.3 Extension Memory Module LQM000 MEMORY ADDR. PORT. ADDR. 1MByte Name Function Memory address switch Sets the first address of an extension memory area. ① Protected memory address switch Sets the write-protected area. ② NOTE An extension memory module receives backup voltage from the CPU when the CPU unit is mounted.

  • Page 41: I/O Module

    3 NAMES AND FUNCTIONS OF PARTS 3.4 I/O Module Model Function LQX100 D.INPUT LQX100 D.INPUT Monitor When an external I/O operation is on, the LED corresponding to it lights. 100-120VAC 100-120VAC Voltage Terminal block I/O devices on the process side are connected. (Some modules are connected through connectors.) Example signals on the terminal block.

  • Page 42: Power Supply Module

    3 NAMES AND FUNCTIONS OF PARTS 3.5 Power Supply Module The power supply module of the same type is used for the CPU and the I/O unit. LQV000 LQV000 POWER POWER DC5V SERVICE CHECK POWER AC100-120V INPUT Power supply modules Name Type Remarks...
  • Page 43 3 NAMES AND FUNCTIONS OF PARTS Name Function Power indicating LED Lights when the power switch is turned on. ① (POWER) Voltage check terminal Checks the voltage of the 5 V output. (Normal: 4.75 to 5.25 V) ② (DC5V) (Do not use this terminal for other than voltage check.) Voltage check terminal Check the 0 V reference voltage.

  • Page 44: Mount Base

    3 NAMES AND FUNCTIONS OF PARTS 3.6 Mount Base The mount base is used to secure CPU modules (or remote I/O station modules), power supply modules, and I/O modules. Two types of mount bases are available for the CPU unit and I/O unit.

  • Page 45: Installation

    4 INSTALLATION...

  • Page 46: Installation

    4 INSTALLATION 4.1 Installation Remote I/O cables can be connected to two communications lines (RI/O-1 and RI/O-2). Each line can connect up to 12 I/O units (a total of 24 I/O units with the two lines). Make sure that the distance between the CPU unit and the I/O unit at the far end is within •...

  • Page 47: Clearances

    4 INSTALLATION 4.2 Clearances To ensure normal operation of this product, provide an air inlet/outlet with an air filter on the top and bottom of the enclosure each, allowing clearances between the enclosure and each unit as shown below. These clearances are recommended values, not mandatory. Test-run the system to make sure that the temperature around the module is within allowable limits.

  • Page 48: Outside Dimensions

    LQP000 LQX100 LQX100 LQV000 D.INPUT D.INPUT LADDER STOP MODE POWER SIMU NORM CPU RUN PROTECT RESET HITACHI S10mini 100-120VAC 100-120VAC DC5V SERVICE CHECK POWER Center AC100-120V INPUT Power supply module CPU module DI module DI module Front view (modules mounted on a 2-slot mount base)
  • Page 49 D.INPUT D.INPUT LQV200 LQX100 LQX100 LADDER LQP000 STOP MODE POWER NORM SIMU CPU RUN PROTECT RESET HITACHI S10mini 100-120VAC 100-120VAC DC5V SERVICE CHECK Center POWER AC200-240V INPUT Power supply module CPU module DI module DI module Front view (modules mounted on a 2-slot mount base)

  • Page 50: Securing The Mount Base

    4 INSTALLATION 4.4 Securing the Mount Base Secure the mount base to the internal vertical surface of the back of the enclosure. Do not mount it horizontally or make it face up or down. Modules are designed so that they provide the best heat dissipation efficiency when they are installed on that vertical surface.

  • Page 51: Securing Modules

    4 INSTALLATION 4.5 Securing Modules When mounting the module for the first time, detach the dust cover from the mount base connector. Before leaving the module out of the mount base for a long period of time, seal the mount base connector with the dust cover to protect the connector. Dust entering the inside of the connector can cause malfunctioning or failures.
  • Page 52 4 INSTALLATION DANGER An external supply voltage will cause electrical shock hazards if you mount or demount the module or connect or disconnect the cable with the power switch turned on and then touch the power terminal by accident. Also, this hardware unit may be damaged due to a short circuit or noise.
  • Page 53 4 INSTALLATION REQUIREMENT Tighten the screws fully. Inadequately tightened screws can cause malfunctioning, smoking, or firing. Damage to the module can result from static electricity. Discharge static charges from your body before setting switches, connecting or disconnecting the cables, or inserting or removing the connectors. - 35 -...
  • Page 54 THIS PAGE INTENTIONALLY LEFT BLANK.

  • Page 55: Wiring

    5 WIRING...

  • Page 56: Cable Specifications

    (CO-EV-SX-1P × 0.75SQ) per line) • 0.3 mm (CO-EV-SB-1P × 0.3SQ) Recommended cables • CO-EV-SX-1P × 0.75SQ Manufactured by • CO-EV-SB-1P × 0.3SQ Hitachi Cable, Ltd. 150 Ω Resistance of terminating resistor 150 Ω For middle Characteristic impedance distances Attenuation ratio...

  • Page 57: Wiring The Power Supply

    5 WIRING 5.2 Wiring the Power Supply Insulate the input power supply for the S10mini from the control power supply by means of an isolating transformer with electrostatic shielding. Below are wiring diagrams when insulating transformers are installed in the power distribution panel and S10mini. When an insulating transformer is installed in the power distribution panel Power distribution panel S10mini...
  • Page 58 5 WIRING Sample wiring inside the S10mini CPU unit 2 mm or more 2 mm or more 2 mm or more I/O unit Terminal block Shielded grounding line Insulating transformer Panel grounding with electrostatic shielding Grounding terminal for the PCs unit. (Insulate this grounding terminal from the panel.) 5.5 mm...

  • Page 59: Wiring For Grounding

    MODE MODE NORM NORM SIMU SIMU POWER POWER PROTECT PROTECT CPU RUN CPU RUN RESET RESET HITACHI S10mini 100-120VAC 100-120VAC 100-120VAC 100-120VAC DC5V DC5V SERVICE SERVICE CHECK CHECK POWER POWER The SHD terminals (A4, A9, B3, and B8) in the CPU modules are connected internally to the FG (B9) terminal.
  • Page 60 RI/O LQV000 LQS000 RI/O LQX100 D.INPUT LQX100 D.INPUT RI/O POWER ST.NO HITACHI HSC-1000 100-120VAC 100-120VAC DC5V SERVICE CHECK POWER Do not ground the FG terminal on the RI/O station module. AC100-120V Terminal block...

  • Page 61: Wiring The Power Supply Module

    5 WIRING DANGER An external supply voltage will cause electrical shock hazards if you mount or demount the module or connect or disconnect the cable with the power switch turned on and then touch the power terminal by accident. Also, this hardware unit may be damaged due to a short circuit or noise.

  • Page 62: Wiring For The Pcs Ok Signal

    LADDER STOP MODE PCs OK SIMU NORM CPU RUN PROTECT Coil load (B1) RESET HITACHI S10mini Fuse Twisted-pair cable PCs OK (B2) 12 to 24 VDC, 2A 48 VDC, 0.5 A 100 VDC, 0.1 A SHD (B3) AC power supply...

  • Page 63: Wiring Remote I/O Cables

    5 WIRING 5.6 Wiring Remote I/O Cables The CPU unit has two remote I/O cable ports (RI/O-1 and RI/O-2), each of which can connect • up to 12 I/O units. The remote I/O cable ports, RI/O-1 and RI/O-2, on the I/O unit are connected internally. •...

  • Page 64: Examples Of Improper Wiring

    5 WIRING 5.6.1 Examples of improper wiring Improper wiring as shown below causes waveforms on the lines to be distorted, resulting in communication errors. Make sure that the cables are connected properly. CPU unit I/O unit I/O unit I/O unit Terminated Terminated RI/O...

  • Page 65: Examples Of Remote I/O Cable Wiring

    MODE 100 Ω ⎯ NORM SIMU CPU RUN PROTECT ⎯ ⎯ ⎯ RESET HITACHI S10mini Ω (A6) Setting for termination with a 100 Ω resistor Setting for termination (A7) with a 150 Ω resistor (A8) (A9) RI/O-1 RI/O cable: 100 m or less...

  • Page 66: Setting Terminating Resistors

    5 WIRING 5.6.3 Setting terminating resistors When a specified cable is used, it must be terminated with a built-in 100 Ω or 150 Ω resistor by connecting terminals, as shown below. When using a non-specified cable and terminating it with a resistor having a resistance other than 100 Ω or 150 Ω, insert a resistor between signal input terminals A and B.
  • Page 67 5 WIRING DANGER Never touch the terminal block while the system is energized. Electrical shock hazards can result if you touch the terminal block while the system is energized. PROHIBITION Do not install, wire, handle, or remake the programmable controller beyond such an extent as may be defined in this manual.
  • Page 68 THIS PAGE INTENTIONALLY LEFT BLANK.

  • Page 69: Settings

    6 SETTING...

  • Page 70: Outline Of I/O Number Settings

    6 SETTING 6.1 Outline of I/O Number Settings Assign I/O numbers to the mounted CPU units and I/O units, as described below. Unit Item to set Description CPU unit Mounting status of PI/O modules If I/O modules are mounted on the CPU mount base, set this item to “PI/O mounted.” The station number 00 will then be assigned to the CPU unit.

  • Page 71: Configuration And Assignment Range Of I/O Numbers

    6 SETTING 6.2 Configuration and Assignment Range of I/O Numbers An I/O number consists of four alphanumeric characters, as explained below. Configuration Input/output type Station number (X: input, Y: output) (00 to 7F) I/O number (X000 to XFFF or Y000 to YFFF) Assignment range CPU unit When an I/O module is...

  • Page 72: Setting I/O Numbers

    Jumper MODE SIMU NORM CPU RUN PROTECT plug No. Jumper plugs Connected Not connected RESET HITACHI S10mini 1: FREE/FIX FREE 2: HOLD HOLD RESET 3: 128 I/O points 4: 64 I/O points 16 points 128 points 5: 32 I/O points...

  • Page 73: Setting The Mounting Status Of Pi/O Modules

    STOP MODE NORM SIMU CPU RUN PROTECT RESET HITACHI S10mini Jumper plugs NOTE At PI/O mounting, attach a terminator (150 Ω) to those ports to which the remote I/O cable is not connected. Item to set Setting of jumper plug 6...

  • Page 74: Setting Partition Status (Free/Fix)

    CPU module LQP000 CPU-S LADDER STOP MODE NORM SIMU CPU RUN PROTECT Item to set RESET Setting of jumper plug 1 HITACHI S10mini Jumper plugs Connected Not connected (factory setting) FREE FREE/FIX setting RI/O station module LQS000 RI/O RI/O ST.NO...
  • Page 75 6 SETTING Differences between FREE and FIX Setting FREE X000 and later Y000 and later X000 and later Up to X Up to X Up to Y Y000 and later Up to Y Unit Unit Slots in which to mount I/O modules There is a Any slot can be restriction...

  • Page 76: Setting The Number Of I/O Points

    I/O points LQP000 CPU-S LADDER Connected Connected Connected STOP MODE SIMU NORM CPU RUN PROTECT RESET HITACHI S10mini (factory Jumper plugs setting) Connected Connected Not connected Connected Not connected Connected Connected Connected Not connected RI/O station module Terminal block...
  • Page 77 6 SETTING Number of I/O points and I/O number The first I/O number and the range of I/O numbers are determined as follows ---- • First I/O number: The first two digits are determined by the set station number. • Range: The range of I/O numbers is automatically determined, according to the settings of the number of I/O slots on the mount base, the number of I/O points occupied by each slot on the mount base, and the partition status.
  • Page 78 6 SETTING Example 2: I/O numbers assigned and number of points occupied when the first I/O number is 000 and the partition status is set to FIX Number of I/O points Input 0 X000 to X00F 0 X000 to X01F 0 X000 to X03F 0 X000 to X07F numbers...

  • Page 79: Setting Do Output Status

    CPU module LQP000 CPU-S LADDER STOP MODE SIMU NORM CPU RUN PROTECT RESET HITACHI Setting of jumper plug 2 S10mini Item to set Jumper plugs Not connected Connected Output mode HOLD RESET (Factory setting) RI/O module RI/O...

  • Page 80: Setting Station Numbers

    40 to 7E. Remote I/O station module RI/O LQS000 I/O number RI/O ST.NO U: First digit ST.NO Input/output type HITACHI HSC-1000 L: Second digit (X: input, Y: output) First Setting of ST.NO I/O number Channel Remarks...
  • Page 81 6 SETTING Example of setting station numbers and I/O numbers Suppose that one CPU unit and four I/O units are installed in different locations. Then set station numbers and I/O numbers, as shown below. CPU unit (2 slots, 16-point modules) 1 000 to 00F 2 010 to 01F Slot number...

  • Page 82: Setting An Extension Memory Module

    6 SETTING 6.4 Setting an Extension Memory Module Setting a memory address Allocate memory areas in an extension memory module in 1 MB units within the range of /100000 to /4FFFFF. To do this, use the “ADDR.” rotary switch on the front of the module, as shown below.
  • Page 83 6 SETTING Write-protecting memory The data in extension memory can be write-protected so that it is not overwritten with C programs. Set the memory areas to be write-protected with the “PROT.ADDR.” rotary switch on the front of the module, as shown below. Setting of the Area to be write-protected Size...
  • Page 84 THIS PAGE INTENTIONALLY LEFT BLANK.

  • Page 85: Operation Procedures

    7 OPERATION PROCEDURES...

  • Page 86: Overview

    7 OPERATION PROCEDURES 7.1 Overview Operations should be carried out as flowcharted below. The user program (application) needs to be loaded only when you run the programmable controller for the first time. (It will be backed up by the battery thereafter.) For details, refer to software manual supplied with the programming tool.

  • Page 87: Procedures

    STOP MODE SIMU NORM Mode switch PROTECT CPU STOP (MODE) RESET Protection switch HITACHI S10mini (PROTECT) Note: Immediately after power-up, the indicator may display unpredictable character string instantaneously. This is not a failure. 7.2.2 STOP mode Setting LQP000 LADDER STOP...

  • Page 88: Run (Ladder Program Execution) Mode

    MODE to RUN. SIMU NORM CPU RUN PROTECT • Set the mode switch (MODE) to NORM. CPU status RESET HITACHI S10mini The user program (ladder) is executed. 7.2.4 SIMU (simulated ladder program execution) mode Setting LQP000 LADDER STOP Set the CPU operation switch (LADDER) to...

  • Page 89: Protect On Mode

    ON.) PROTECT CPU RUN CPU status RESET • When a user-created C program is HITACHI S10mini executed, the operating system, the ladder diagram program, and other programs are protected. • The PROTECT switch cannot protect optional extension memory.
  • Page 90 7 OPERATION PROCEDURES PROTECT switch The PROTECT switch protects the system area so that it is not destroyed by user tasks coded in C or FA-BASIC. This switch has no effect for arithmetic functions including user arithmetic functions. Memory is protected in the following range: /000000 OS ROM System...

  • Page 91: Explanation Of Operation

    8 EXPLANATION OF OPERATION...

  • Page 92: Ladder Diagram Program

    8 EXPLANATION OF OPERATION 8.1 Ladder Diagram Program 8.1.1 Execution Execution conditions • CPU operation switch (LADDER): RUN • Mode switch (MODE): NORM or SIMU (In SIMU mode, only the ladder diagram program is executed without remote I/O transfer being performed.) Starting the ladder diagram program The ladder diagram program can be started in one of two ways: cyclically or repeatedly.

  • Page 93: Program Execution Order

    8 EXPLANATION OF OPERATION 8.1.2 Program execution order Create a ladder diagram program in such a way that control flows in the order of processing from the top. Otherwise, much time is wasted, hampering high-speed processing. Correct ladder diagram program example Since the ladder diagram program shown below is created in the order in which processing is performed, its processing is completed within the sequence cycle time.

  • Page 94: Executing Arithmetic Functions

    8 EXPLANATION OF OPERATION 8.1.3 Executing arithmetic functions Arithmetic functions are executed according to the status (On or Off) of excitation, as described below. Starting operation Operation starts when the status of excitation is On. The value of XW100 is added to XW110 and the result is output to YW040.

  • Page 95: Remote I/O

    8 EXPLANATION OF OPERATION 8.2 Remote I/O 8.2.1 Remote I/O transfer The table below shows remote I/O transfer by the CPU module in each mode. Settings of the switches on the CPU module Setting of the power CPU operation switch RI/O transfer switch RESET...

  • Page 96: Processing Time

    8 EXPLANATION OF OPERATION 8.3 Processing Time Processing time is measured from when an input signal enters the input module until it is output from the output module. That time is the sum of (1) to (4) shown below. Remote I/O line Remote I/O line External Output...

  • Page 97: Clock Features

    8 EXPLANATION OF OPERATION 8.4 Clock Features This section describes the features of the clock as well as how to set it. 8.4.1 Clock control system registers Clock control system registers are used by the ladder diagram program for real-time control. They consist of time registers, a time control register, and a time display control register.
  • Page 98 8 EXPLANATION OF OPERATION Time control register The time control register controls the setting of the current time of the day. Its bit assignment is shown below. (MSB) 2 (LSB) SW200 1/0 Unused S202: Data setting and start (1: data setting and start, 0: normal use) S201: Clock stop (1: stop requested, 0: stop not requested) S200: Clock update (1: clock being updated, 0: clock update stopped) Setting a time...

  • Page 99: Setting The Time Using The Ladder Diagram Program

    8 EXPLANATION OF OPERATION 8.4.2 Setting the time using the ladder diagram program The ladder diagram program shown below sets the time information stored in F registers FW100 to FW106 in time registers SW280 to SW2E0 when X000 is turned on. This subsection describes only the items required for creation of a ladder diagram program.

  • Page 100: Updating The Date

    8 EXPLANATION OF OPERATION 8.4.3 Updating the date The date is automatically updated as follows: January, March, May, July, August, October, or December 31 → first day of the next month April, June, September, or November 30 → first day of the next month February 28 in a common year →...

  • Page 101: Conditions Of The I/O Input/Output Registers And Internal Registers In Case Of Errors

    8 EXPLANATION OF OPERATION 8.5 Conditions of the I/O Input/Output Registers and Internal Registers in Case of Errors Procedure and Initialization Startup Normal operation Error condition Power-up STOP STOP→ PROT. Reset-off → Name OS loading STOP I/O error (*1) CPU down →RUN IDLE SIMU, RUN...

  • Page 102: Restrictions On Mounting Option Modules

    8 EXPLANATION OF OPERATION 8.6 Restrictions on Mounting Option Modules Description Model CPU unit I/O unit Remarks Power supply LQV000 Shared by CPU and I/O unit LQV100 Shared by CPU and I/O unit LQV020 Shared by CPU and I/O unit LQV200 Shared by CPU and I/O unit ⎯...
  • Page 103 8 EXPLANATION OF OPERATION (*1) Up to two modules of LQE010/LQE510/LQE015/LQE515/LQE030/LQE530 can be mounted per CPU. Set either module as main, the other as subordinate. (*2) Assign addresses to avoid duplication. (*3) Up to four units of the CPU module LQP000 can be mounted. (*4) The number of concurrent ON points is limited by the ambient temperature.

  • Page 104: Output Current Of The Power Supply Module

    8 EXPLANATION OF OPERATION 8.7 Output Current of the Power Supply Module When the power supply module is LQV000, LQV020, or LQV100 and the ambient temperature is high, output current is restricted as shown below. Use the module after being sure that current consumption of it is less than output current.
  • Page 105 8 EXPLANATION OF OPERATION Current consumptions of available option modules Description Model Module REV Current consumption LQP000 Before the [H] LQP010 Before the [H] 1500 mA or less LQP011 Before the [I] LQP120 Before the [F] LQP000 [I] or later LQP010 [I] or later 1630 mA or less...
  • Page 106 8 EXPLANATION OF OPERATION Current consumptions of available I/O modules Current Module name Model consumption RI/O (remote I/O station) LQS000 150 mA or less J.STATION (J-station) LQS020 700 mA or less IR.STATION (IR station) LQS021 700 mA or less D.STATION (D-station) LQS070 300 mA or less LQX110...

  • Page 107: Memory Backup

    8 EXPLANATION OF OPERATION 8.8 Memory Backup The user program is stored in the RAM (Random Access Memory) and backed up by lithium battery at a power outage. Replace the lithium battery before it is over backup guaranteed time. When the power is turned off while the battery is run down or the battery voltage becomes low, the contents in the backup memory may be damaged.
  • Page 108 8 EXPLANATION OF OPERATION CPU module REV check position Check the bar code label to confirm the CPU module REV as illustrated below. Bar code label 001 013 D R147501 CPU module REV The life expectancy of a lithium battery under the ambient temperature and humidity is seven years.
  • Page 109 8 EXPLANATION OF OPERATION If the power supply is shut off for three minutes or longer while the CPU module indicator shows “CPU CELL” (Battery expired), backup memory content may be lost. Furthermore, the backup memory may be lost if the CPU module has a lithium battery and is stored unused for a long time (longer than the preset backup assurance period).

  • Page 110: Output Timing Of The Pcs Ok Signal

    8 EXPLANATION OF OPERATION 8.9 Output Timing of the PCs OK Signal When the ladder program execution switch on the CPU module is switched from STOP to RUN, output of the PCs OK signal changes as shown below. Ladder program STOP execution switch RUN (NORM)

  • Page 111: Maintenance

    9 MAINTENANCE...

  • Page 112: Preventive Maintenance

    9 MAINTENANCE 9.1 Preventive Maintenance To use the S10mini under its best condition, check the items listed below on a day-to-day basis or periodically (at least twice per year). Item to check ① Appearances of the modules ② States of the LEDs and indicator ③...
  • Page 113 9 MAINTENANCE ⑥⑦ Power supply voltage Check to see if the I/O voltage of the power supply module and the voltage of the external power supply are within allowable limits of specifications. Too low or high a power supply voltage may cause the system to malfunction. Power supply module specifications are as follows: Input voltage regulation --- LQV000: 85 to 132 VAC LQV100: 85 to 132 VAC, 85 to 132 VDC...
  • Page 114 9 MAINTENANCE Useful life of the relay For an I/O module, such as the LQY100 or LQY140, that contains a relay, the useful life of the relay contacts must be considered. Plan periodic replacement of the I/O module if it is used in a system in which the relay opens and closes frequently or either the output voltage or the power current is high.

  • Page 115: Replacing The Backup Battery

    9 MAINTENANCE 9.2 Replacing the Backup Battery When the backup battery is low, the message “CPU CELL” appears in the indicator on the CPU module. This requires that the battery be replaced. Replace the backup battery periodically by establishing the intervals of replacement to meet the size of extension memory and the operating environment from a preventive maintenance standpoint.
  • Page 116 Steps ⑤ to ⑧ below must be completed within five minutes. To speed up replacement, prepare the replacement battery (ER6T-3WK41-Z from Hitachi Maxell, Ltd.) in advance. ⑤ To remove the battery connector from the PC board, carefully pull out the battery connector as shown below in the direction of the arrow.

  • Page 117: Disposing Of Used Batteries

    9 MAINTENANCE 9.2.2 Disposing of used batteries General notes on asking the agent to dispose of used batteries 1. Collection and vessel Collect used batteries in such a way that a short circuit, charging circuit, or overdischarging circuit is not formed between batteries. Also note the following points: Make sure that the vessel in which to collect used batteries is made of insulating •...
  • Page 118 9 MAINTENANCE Manifesto information Used lithium batteries (ER batteries) must be handled as industrial wastes. Ask a professional to dispose of used batteries. REQUIREMENT If the battery is handled improperly, it may catch fire or explode. Some used batteries may still have a considerable amount of charge. To deliver such used batteries to a waste disposal site safely, follow the general rules for collection, packing, and transportation.

  • Page 119: Troubleshooting

    LQX100 LQV000 LQP000 LADDER D.INPUT D.INPUT STOP MODE POWER SIMU NORM CPU RUN PROTECT RESET HITACHI S10mini 100-120VAC 100-120VAC DC5V SERVICE CHECK POWER AC100-120V DI/DO module Power supply module CPU module CPU unit (2-slot mount base) Power indicating LED LEDs...
  • Page 120 9 MAINTENANCE Diagnosis by checking the power indicating LED status and the message in the indicator When the power indicating LED on the power supply module is off, check the power supply voltage and waveform. While the CPU is running normally, the indicator on the CPU module displays one of the following messages: Message Explanation...
  • Page 121 9 MAINTENANCE Diagnosis by replacing modules If the cause of the failure cannot be corrected by diagnosis by checking the operation indicator LED status and the message in the indicator, replace the module as described below. Module to replace Failure Action Power supply module The LED does not light.
  • Page 122 9 MAINTENANCE Error messages (2/3) Error Message Explanation Action If ∆∆ is one of the values 10-4F, the error is an EX∆∆ PRT Handle the PROT ERR error according to the ∆∆: See the next extension memory protection error. information supplied under “Diagnosis by checking the power indicating LED status and page.(*) the message in the indicator”...
  • Page 123 9 MAINTENANCE Error messages (3/3) Error Message Explanation Action SVC ERR CPMS macro instruction parameter error occurred Check parameters in the macro instruction and review the user task. FBRAN ER Floating-point operation: Branch setting when a An error occurred when a floating-point comparison is disabled operation was in progress.
  • Page 124 9 MAINTENANCE Clearing all the memory If the indicator does not turn on or “ROM IDLE” or “LOAD OS” appears when the power supply is turned on, hold down the reset switch for more than 20 seconds. If doing so will not solve the problem, clear the memory by performing the procedure described below.
  • Page 125 9 MAINTENANCE ② Select [PCs edition (E)]-[Initiate PCs memory (I)] from the [Utility (U)] menu of the Ladder Chart System. ③ The following confirmation message is displayed. Click the button. ④ The following message is displayed. Reset the PCs, or power it down and then back up again.
  • Page 126 9 MAINTENANCE Memory clearing when the Windows® version of the tool is ready for online operation or when the Ladder Chart System is not purchased yet by the user. If neither the Windows® version of the tool nor the PCs can be placed into an online state (due to, for instance, an “line error”), discharge all the memory backup energy and clear the memory by performing the procedure described below.
  • Page 127 9 MAINTENANCE ⑤ Remove the lock arm of the battery connector and slowly pull the battery connector out of the PC board in the direction of the arrow as shown below. Pull out in this direction. Battery connector Lock arm PC board ⑥...
  • Page 128 THIS PAGE INTENTIONALLY LEFT BLANK.

  • Page 129: Specifications

    10 SPECIFICATIONS...
  • Page 130 10 SPECIFICATIONS General specifications Item Specifications Remarks Temperature Operation 0 to 55°C Rate of temperature change: 10°C/h or lower Storage -20 to 75°C Relative humidity Operation 30 to 90%RH Non-condensing Storage 10 to 90%RH Resistance to vibration Compliant with JIS C0040 Frequency: 10 to 150 Hz;...
  • Page 131 10 SPECIFICATIONS Specifications of CPU and RI/O module performance Specifications TYPE-S TYPE-H TYPE-F TYPE-D Item Remarks (model: (model: (model: (model: LQP000) LQP010) LQP011) LQP120) Number of I/O points 2048 (extendable to 4096) Programming Ladder diagram Option language HI-FLOW Option Option Instructions Ladder instructions Application instructions...
  • Page 132 10 SPECIFICATIONS External input/output specifications Specification Item Remarks Models S, H, F, and D Remote I/O Transfer rate 768 kbps Number of lines Number of units Up to 12 per line Number of words 64 (1024 points) per port to be transferred Insulation Transformer Error check...

This manual is also suitable for:

S10mini hS10mini fS10mini d

Table of Contents
