Models - Graco M2K Instructions - Parts Manual

Models

Models
Sprayer Pump Mounting
Type Ratio
1:1
2:1
3:1
Air Spray
4:1
5:1
6:1
1:1
2:1
3:1
Air Assisted
Air Spray
4:1
5:1
6:1
1:1
2:1
3:1
Airless
4:1
5:1
6:1
Airless - For
Split-Batch
1:1
Polyester
Applications
4
Type Model
Cart 24V868 1/4 ID Mix Fluid Hose x 25 ft. (7.6 m)
Wall 24V874
Cart 24V869 1/4 ID Mix Fluid Hose x 25 ft. (7.6 m)
Wall 24V875
Cart 24V870 1/4 ID Mix Fluid Hose x 25 ft. (7.6 m)
Wall 24V876
Cart 24V871 1/4 ID Mix Fluid Hose x 25 ft. (7.6 m)
Wall 24V877
Cart 24V872 1/4 ID Mix Fluid Hose x 25 ft. (7.6 m)
Wall 24V878
Cart 24V873 1/4 ID Mix Fluid Hose x 25 ft. (7.6 m)
Wall 24V879
Cart 24V880 3/16 ID Mix Fluid Hose x 25 ft. (7.6 m)
Wall 24V886
Cart 24V881 3/16 ID Mix Fluid Hose x 25 ft. (7.6 m)
Wall 24V887
Cart 24V882 3/16 ID Mix Fluid Hose x 25 ft. (7.6 m)
Wall 24V888
Cart 24V883 3/16 ID Mix Fluid Hose x 25 ft. (7.6 m)
Wall 24V889
Cart 24V884 3/16 ID Mix Fluid Hose x 25 ft. (7.6 m)
Wall 24V890
Cart 24V885 3/16 ID Mix Fluid Hose x 25 ft. (7.6 m)
Wall 24V891
Cart 24V892 3/16 ID Mix Fluid Hose x 25 ft. (7.6 m)
Wall 24V898
Cart 24V893 3/16 ID Mix Fluid Hose x 25 ft. (7.6 m)
Wall 24V899
Cart 24V894 3/16 ID Mix Fluid Hose x 25 ft. (7.6 m)
Wall 24V901
Cart 24V895 3/16 ID Mix Fluid Hose x 25 ft. (7.6 m)
Wall 24V902
Cart 24V896 3/16 ID Mix Fluid Hose x 25 ft. (7.6 m)
Wall 24V903
Cart 24V897 3/16 ID Mix Fluid Hose x 25 ft. (7.6 m)
Wall 24V904
Cart 24W609 3/16 ID Mix Fluid Hose x 25 ft. (7.6 m) +
Fluid Filters and
Fluid/Air Hose
None
None
None
None
None
None
None
None
None
None
None
None
None
None
None
None
None
None
Remote Manifold to Airless Gun
10 ft. (3 m)
Air
Lower A Lower B Motor
50cc 50cc
100cc 50cc
75cc 25cc
2.5 in.
100cc 25cc
125cc 25cc
150cc 25cc
50cc 50cc
100cc 50cc
75cc 25cc
7.5 in.
100cc 25cc
125cc 25cc
150cc 25cc
50cc 50cc
100cc 50cc
75cc 25cc
7.5 in.
100cc 25cc
125cc 25cc
150cc 25cc
25cc 25cc 4.5 in.
333309K
