Identity Schedule - Aventics CONTROLAIR HC-2 Series Service Information

Model New Old
Complete Complete
Part Number Part Number
R431002835 P –050975-00001
R431002836 P –050975-00002
R431002837 P –050975-00003
R431002838 P –050975-00004
HC-2-X P –050975-00008
R434002034 P –052540-00004
R434002050 P –052878-00001
R434001203 P –065238-00000
P –065689-00001
P –065689-00003
R434001176 P –067508-00003
R431002839 P –050976-00001
R431002840 P –050976-00002
R431002841 P –050976-00003
R431002842 P –050976-00004
R431002843 P –050976-00008
R431002844 P –050976-00015
R434001989 P –052943-00001
HC-2-FX R434001976 P –055781-00001
R434001219 P –065123-00001
P –065123-00002
R431006565 P –065123-00003
P –063511-00001
P –063511-00003
P –063511-00004
R431003824 P –055582-00001
R431003825 P –055582-00002
HC-2-LX R431003826 P –055582-00003
R431003827 P –055582-00004
P –068520-00003
R431009114 P –051206-00001
R431002892 P –051206-00002
R431002893 P –051206-00003
HC-2-SX R431002894 P –051206-00004
R431002036 P –052518-00002
R431002035 P –052518-00003
R431007030 P –067197-00003
* Cam Portion - less valve portion, pipe bracket, screws and nameplate
Note 1- Same as R431002838 (P -050975-00004) except less yoke, handle and ball Items 52, 53 & 54
Note 2- Same as R431002835 (P -050975-00001) except long handle P -050979 Item 53
Note 3 - Same as P -050975-00000 press range setting.
Note 4 - Same as R431002835 (P -050975-00001) except items 38, 52 & 53 are chrome plated or stainless steel
Note 5 - Same as R431002837 (P -050975-00003) except items 38, 52 & 53 are chrome plated or stainless steel
Note 6 - Same as R431002835 (P -050975-00001) except item 56 is P50878-0002 and less centering spring
Note 7 - Same as R431002839 (P -050976-00001) except less escutcheon plate item 67.
Note 8 - Same as R431002839 (P -050976-00001) except less escutcheon plate and holes are plugged.
Note 9 - Same as R431002839 (P -050976-00001) except items 38, 52 & 53 are chrome plated or stainless steel
Note 10 - Same as R431002840 (P -050976-00002) except items 38, 52 & 53 are chrome plated or stainless steel
Note 11 - Same as R431002841 (P -050976-00003) except items 38, 52 & 53 are chrome plated or stainless steel
Note 12 - Same as R431002839 (P -050976-00001) except all exterior surfaces are painted with black epoxy paint.
Note 13 - Same as R431002841 (P -050976-00003) except all exterior surfaces are painted with black epoxy paint.
Note 14 - Same as R431002842 (P -050976-00004) except all exterior surfaces are painted with black epoxy paint.
Note 15 - Same as R431003826 (P -055582-00003) except items 38, 52 & 53 are chrome plated or stainless steel.
Note 16 - Same as R431002892 (P -051206-00002) except less yoke, handle and ball Items 52, 53 & 54.
Note 17 - Same as R431002893 (P -051206-00003) except less yoke, handle and ball Items 52, 53 & 54.
Note 18 - Same as R431002892 (P -051206-00003) except latches in opposite maximum pressure position.
HC-2 IDENTITY SCHEDULE
Control New
Pressure Control Control Spring
Range (PSI) Spring P/N & Code (Ref. # 29)
0 - 65 R431003732 P55442 Brown
0 - 100 R431000043 526749 Yellow
0 - 125 R431000099 540577 Light blue
0 - 150 R431003731 P55441 Red
0 - 30 R431005475 P60295 Dark Blue
0 - 150 R431005475 P55441 Red
0 - 65 R431003732 P55442 Brown
35 - 85 R431000099 P64822 Silver
0 - 65 R431000099 P55442 Brown
0 - 125 R431003732 540577 Light Blue
0 - 125 R431000043 540577 Light Blue
0 - 65 R431003732 P55442 Brown
0 - 100 R431000043 526749 Yellow
0 - 125 R431000099 540577 Light blue
0 - 150 R431003731 P55441 Red
0 - 30 R431005475 P60295 Dark Blue
0 - 175 R431000099 P54159 Silver
0 - 65 R431003732 P55442 Brown
0 - 65 R431000043 P55442 Brown
0 - 65 R431003732 P55442 Brown
0 - 100 R431000043 540577 Light blue
0 - 125 R431000099 P55441 Red
0 - 65 R431003732 P55442 Brown
0 - 100 R431000099 540577 Light blue
0 - 150 R431003731 P55441 Red
0 - 65 R431003732 P55442 Brown
0 - 100 R431000043 526749 Yellow
0 - 125 R431000099 540577 Light blue
0 - 150 R431003731 P55441 Red
0 - 125 R431000099 540577 Light blue
0 - 65 R431003732 P55442 Brown
0 - 100 R431000043 526749 Yellow
0 - 125 R431000099 540577 Light blue
0 - 150 E321--3731 P55441 Red
0 - 100 R431000043 526749 Yellow
0 - 125 R431000099 540577 Light blue
0 - 125 R431000099 540577 Light blue
Page 7
Old New Cam Old Cam Portion
Part Number Part Number
*Complete *Complete
R431000134 -850253-00000
R431000134 -850253-00000
R431000134 -850253-00000
R431000134 -850253-00000
R431000134 -850253-00000
R431002978 P -052539-00000
R431003028 P -052879-00000
R431000134 -850253-00000
P -065690-00000
R431007052 P -065690-0000
R431000140 P -067283-00000
R431000140 -850259-00000
R431000140 -850259-00000
R431000140 -850259-00000
R431000140 -850259-00000
R431000140 -850259-00000
R431000140 -850259-00000
R431002810 P -065690-00000
R431002810 P -065690-00000
R431000141 -850260-00000
R431000141 -850260-00000
R431000140 -850259-00000
P -065690-00000
R431000141 -850260-00000
R431000140 -850259-00000
R431000151 -850430-00000
R431000151 -850430-00000
R431000151 -850430-00000
R431000151 -850430-00000
P -068525-00000
R431002895 P -051207-00000
R431000151 -850430-00000
R4310001512 -850430-00000
P -068525-00000
R431002987 P -052649-00000
R431002987 P -052649-00000
R431002896 P -051207-00001
** Valve Portion - less pipe bracket, screws and cam portion.
New Valve Old Valve Remarks
Part Number Part Number
**Complete **Complete
R431003829 P –055583-00001
R431003830 P –055583-00002
R431003831 P –055583-00003
R431003832 P –055583-00004
R431003833 P –055583-00008
R431003832 P –055583-00004
R431003829 P –055583-00001
R431003835 P –055583-00016
R431003829 P –055583-00001
R431003831 P –055583-00003
R431003831 P –055583-00003
R431003829 P –055883-00001
R431003830 P –055583-00002
R431003832 P –055583-00003
R431003832 P –055583-00004
R431003833 P –055583-00008
R431003834 P –055583-00015
R431003829 P –055583-00001
R431003829 P –055583-00001
R431003833 P –055583-00008
R431003834 P –055583-00015 Note 10
R431003832 P –055583-00004 Note 11
R431003829 P –055583-00001
R431003831 P –055583-00015 Note 13
R431003832 P –055583-00004 Note 14
R431003829 P –055883-00001
R431003830 P –055583-00002
R431003831 P –055583-00003
R431003832 P –055583-00004
R431003831 P –055583-00003 Note 15
R431003829 P –055883-00001
R431003830 P –055583-00002
R431003831 P –055583-00003
R431003832 P –055583-00004
P –055583-00002 Note 16
R431003830
R431003831 P –055583-00003 Note 17
R431003832 P –055583-00004 Note 18
Note 1
Note 2
Note 3
Note 4
Note 5
Note 6
Note 7
Note 8
Note 9
Note 12
