Figure 1-1. ATtiny3217 Xplained Pro Evaluation Kit Overview
CURRENT MEASUREMENT
HEADER
USER LED0
MCU CURRENT
MEASUREMENT
SELECT JUMPER
I/O CURRENT
MEASUREMENT
SELECT JUMPER
QTOUCH® BUTTONS
©
2020 Microchip Technology Inc.
ATtiny3217 Xplained Pro
SW0 USER BUTTON
SW1 USER BUTTON
DEBUG USB
EXTENSION 3
HEADER
User Guide
Introduction
POWER
HEADER
UPDI DEBUG
FOR EXTERNAL
DEBUGGER
ATTINY3217
EXTENSION 1
HEADER
32.768 kHz
CRYSTAL
DS50002765B-page 5
