...........continued
Designat Value Mounted From
or
R406 0R Yes
R407 0R Yes
R408 0R Yes
R414 330R Yes
R415 0R Yes
R416 330R Yes
R417 330R Yes
R420 330R Yes
R425 0R Yes
R426 0R Yes
Figure 4-4. Assembly Drawing Top
©
2020 Microchip Technology Inc.
To
EDBG CDC RX PB2 UART TX
2
EDBG I C SDA PA1 I
2
EDBG I C SCL PA2 I
EDBG CDC TX PB3 UART RX
EDBG SPI MOSI PC2 SPI MOSI
EDBG DGI_GPIO0 PB5 GPIO
EDBG DGI_GPIO1 PB6 IRQ GPIO
EDBG SPI MISO PC1 SPI MISO
EDBG SPI SCK PC0 SPI SCK
EDBG SS PC4 SPI SS
User Guide
ATtiny3217 Xplained Pro
Hardware User Guide
Comment
EDBG CDC and DGI interfaces
to the ATtiny3217
2
C SDA
2
C SCL
