Trane ADAPTIVE CONTROL UCM-CLD Installation Operation & Maintenance page 18

Note:
MMR: Machine shutdown manual reset.
MAR: Machine shutdown automatic reset.
CMR: Circuit shutdown manual reset.
CAR: Circuit shutdown automatic reset.
IFW: Informational warning.
Type of diagnostic
Latched fault - manual reset required
"Press (Next) for more"
Type of circuit shutdown
Latched fault - manual reset required
"Press (Next) for more"
Did diagnostic occur
on Circuit 1 or Circuit 2?
Press (Enter) to
reset circuit 1 diagnostics
Next
Reset Circuit 1 diagnostic
Press (Enter) to
reset circuit 2 diagnostics
Next
Reset Circuit 2 diagnostic
Active fault - can clear automatically
"Press (Next) for more"
Next
Type of diagnostic
A circuit shutdown occurred
but has cleared "Press (Next)"
Next
Type of diagnostic
*** Informational warning ***
"Press (Next) for diagnostic info"
Next
18
Other
CMR/ CAR active
Next
CAR
CMR
Next
Circuit 2
Circuit 1
Enter
Enter
Other
CAR inactive
IFW inactive
IFW active
