Trane AYSVPANL0022AA Series Installer's Manual

ALL phases of this installation must comply with NATIONAL, STATE AND LOCAL CODES
I MPORTANT — This Document is customer property and is to remain with this unit. Please return to service information pack upon completion of work.
WARNING:
L !
This information is intended for use by individuals pos-
sessing adequate backgrounds of electrical and me-
chanical experience. Any attempt to repair a central air
conditioning product may result in personal injury and/or
property damage. The manufacture or seller cannot be
responsible for the interpretation of this information, nor
can it assume any liability in connection with its use.

Application:

This kit is to be used on outdoor units that do not ship
with a service valve panel cover. Part numbers for
kits are shown above. Panels vary by shape, size and
model color.
The manufacturer has a policy of continuous product and product data improvement and it reserves the right to change design and specifications without notice. Representative-only illustrations included in this document.
© 2014 Trane U.S. Inc. 10/14
HAZARDOUS VOLTAGE - DISCONNECT POWER and DISCHARGE
WARNING
Installer's Guide
Service Valve Panel
Cover Kit
*AYSVPANL0022AA
*AYSVPANL0032AA
*AYSVPANL3343AA
*AYSVPANL3545AA
*AYSVPANL0044AA
*AYSVPANL0046AA
*
A or T
CAPACITORS BEFORE SERVICING
LIVE ELECTRICAL COMPONENTS!
During installation, testing, servicing, and troubleshoot-
ing of this product, it may be necessary to work with
live electrical components. Failure to follow all electrical
safety precautions when exposed to live electrical com-
ponents could result in death or serious injury.

Contents:

1 - Panel
2 - 12-18 Screws
1 - Installer's Guide
18-HE95D1-2
