Operator settings
[SOURCE]
Local
Tracer
Default = 6.7°C
Select = - 17.8 to 18.3°C
* If "Limited by cutout setpoint, (+) to change" is
displayed, refer to the section on "Leaving water
temperature cutout" and "Low refrigerant
temperature cutout."
Default = Disable
Default = 5.5 °C
Select = -16 to +2°C
This is difference between the entering and
leaving chilled water temperature.
Default = 1.1°C
Select = 16.6 to 1.1°C
The temperature which is added the chilled water
setpoint, at which the chiller will start.
Operator Chiller operation settings and setpoints
settings
"Press (Next) (previous) to continue"
Setpoint source
"Press (+) (-) to change setting"
Front panel chilled water setpoint
"Press (+) (-) to change setting"
External chilled water setpoint
"Press (+) (-) to change setting"
Design delta temperature setpoint
"Press (+) (-) to change setting"
Front Panel Chilled Water Setpoint
"Press (+) (-) to change setting"
Front Panel Hot Water Setpoint
"Press (+) (-) to change setting"
External Chilled Water Setpoint
"Press (+) (-) to change setting"
External Hot Water Setpoint
"Press (+) (-) to change setting"
Cooling Design Delta Temperature Setpoint
"Press (+) (-) to change setting"
Heating Design Delta Temperature Setpoint
"Press (+) (-) to change setting"
Differential to start setpoint
"Press (+) (-) to change setting"
10
Next
[SOURCE]
Next
All others RTXA
Next
[Disable/Enable]
Next
[Disable/Enable]
[Disable/Enable]
Next
XXX C
XXX C
XXX C
XXX C
XXX C
XXX C
XXX C
