- Page 1 Wireless access point WEP-12ac User manual Firmware version 1.19.3 IP address: 192.168.1.10 Username: admin Password: password...
-
Page 2: Table Of Contents
Wall mounting ............................12 3.4.2 Installing to false ceiling........................13 3.4.3 Removing the device from the bracket....................14 Application A. WEP-12ac antenna patterns ....................15 Application B. Pin array of the device connectors..................16 List of changes............................. 17 2... -
Page 3: Introduction
WEP-12ac device is a Wi-Fi access point of Enterprise class. Purpose: The device is dedicated to be installed inside buildings as an access point and to create a seamless wireless network using several identical access points on a large area. -
Page 4: Device Description
WEP-12ac wireless access point (hereinafter the device) is designed for provision of users' access to high-speed safe network. The device is dedicated to create L2 wireless networks interfacing with a wired network. WEP-12ac is connected to a wired network via 10/100/1000M Ethernet interface and arrange high-speed access to the Internet for devices supporting Wi-Fi technology at 2.4 and 5 GHz. -
Page 5: The Device Technical Parameters
• support for Internet Protocol Security (IPSec); • support for WIDS/WIPS. The figure below shows WEP-12ac application scheme. Figure 1 – WEP-12ac application scheme 2.3 The device technical parameters Table 1 – The device main technical parameters Ethernet WAN interface parameters... - Page 6 WEP-12ac. User manual Wireless interface parameters Standards 802.11a/b/g/n/ac Frequency range 2412–2472 MHz, 4900–5850 MHz Modulation CCK, BPSK, QPSK, 16QAM, 64QAM, 256QAM Operating channels • 11b/g/n: 1–13 (2412–2472 MHz) • 11a/ac: 36-64 (4900–5320 MHz) • 100-144 (5500–5720 MHz) • 149-165 (5745–5825 MHz)
-
Page 7: Design
2.4.1 Device main panel The layout of WEP-12ac is shown in the figure below. Figure 2 – WEP-12ac main panel layout Connectors and controls located on the device main panel are listed in Table 2. Table 2 – Description of ports and controls... -
Page 8: Light Indication
WEP-12ac. User manual 2.5 Light indication The current device state is displayed by Wi-Fi, LAN, Power indicators located on the front panel. The list of indicators’ possible states is given below. ... -
Page 9: Reset To The Default Settings
WEP-12ac. User manual Table 3 – Light indication of device state LED status Device state Wi-Fi solid green Wi-Fi network is enabled flashing green the process of data transmission trough a wireless network LAN solid green (10, 100 Mbps)/solid orange (1000 Mbps) -
Page 10: Installation Order
Approximate radius of coverage area of WEP-12ac with a good-quality signal in case of mounting on a ceiling in typical office: 2,4 GHz — 40–50 m, 5 GHz — 20–30 m. In the absence of obstacles, the coverage radius: 2.4 GHz — up to 100 m, 5 GHz — up to 60 m. - Page 11 WEP-12ac. User manual Material Change of signal level, dB 2.4 GHz 5 GHz Organic glass -0,3 -0,9 Brick -4,5 -14,6 Glass -0,5 -1,7 Plaster slab -0,5 -0,8 Wood laminated plastic -1,6 -1,9 Plywood -1,9 -1,8 Plaster with wirecloth -14,8...
-
Page 12: Installing Wep-12Ac
WEP-12ac. User manual Figure 5 – Scheme of channel allocation between neighboring access points that are located between floors When width of used channel is 40 MHz there is no non-overlapping channels in frequency range of 2.4 GHz. In such cases, you should select channels maximally separated from each other. -
Page 13: Installing To False Ceiling
WEP-12ac. User manual 2. Install the device. Backside view Front view Figure 8 – Device installation 2.1 Connect cables to corresponding connector of the device. -
Page 14: Removing The Device From The Bracket
WEP-12ac. User manual Align holes in metal bracket with holes of armstrong panel and plastic bracket. Align together four boltholes on the plastic bracket and the boltholes on the metal bracket. Screw the brackets to the device surface by using a screwdrive. -
Page 15: Application A. Wep-12Ac Antenna Patterns
WEP-12ac. User manual 4 Application A. WEP-12ac antenna patterns 2.4 GHz 5 GHz... -
Page 16: Application B. Pin Array Of The Device Connectors
WEP-12ac. User manual 5 Application B. Pin array of the device connectors RJ-45 connector pin array The next scheme is used for twisted-pair wiring. Side А: white orange; orange; white green; blue; white blue; green; white brown; brown. RJ-45 connector... -
Page 17: List Of Changes
WEP-12ac. User manual 6 List of changes Document version Issue date Revisions Version 1.19 09.04.2020 Synchronization with firmware version 1.19.3 Version 1.18 24.02.2020 Synchronization with firmware version 1.19.0 Version 1.17 01.10.2019 Synchronization with firmware version 1.18.1 Version 1.16 05.06.2019 Synchronization with firmware version 1.17.0... - Page 18 29 Okruzhnaya Str., Novosibirsk, Russian Federation, 630020 E-mail: techsupp@eltex-co.ru You are welcome to visit ELTEX official website to get the relevant technical documentation and software for ELTEX products or consult a Service Center Specialist on our technical forum. https://eltex-co.com/ https://eltex-co.com/support/downloads/...
