mikroElektronika mikroProg Manual page 15

HD1
VCC-3.3V 1
TRST 3
TDI 5
TMS 7
TCK 9
11
TDO 13
RESET# 15
17
VCC-3.3V 19
ST- Link V2
Figure 6-3: mikroProg™ to ST-Link V2 adapter connection schematics
2 VCC-3.3V
4
6
8
10
12 GND VCC-3.3V
14 GND
16 GND
18 GND TRST
20 GND GND
Page 15
HD2
1 2 TMS
3 4 TCK
5 6 TDO
7 8 TDI
9 10 RESET#
mikroProg
™
