PCIE-1803 8-ch, 24-Bit, 128 kS/s Dynamic Sig-
nal Acquisition PCI Express Card
Startup Manual
Packing List
Before installation, please make sure that you have re-
ceived the following:
• PCIE-1803 DAQ card
• Quick Start User Manual
If anything is missing or damaged, contact your distributor
or sales representative immediately.
User Manual
For more detailed information on this product, please refer
to the PCI-1803 User Manual on Advantech Support Portal:
https://support.advantech.com/support/new_default.aspx.
Declaration of Conformity
FCC Class A
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio fre-
quency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference
to radio communications. Operation of this equipment in
a residential area is likely to cause interference in which
case the user is required to correct interference at his own
expense.
CE
This product has passed the CE test for environmental
specifications when shielded cables are used for external
wiring. We recommend the use of shielded cables. This kind
of cable is available from Advantech. Please contact your
local supplier for ordering information.
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our
support website at:
http://support.advantech.com
This manual is for the PCIE-1803.
Part No. 2041180300
Printed in Taiwan
1st Edition
November 2019
Overview
The Advantech PCIE-1803 is a high-performance data
acquisition module specifically designed for sound and
vibration applications.
Specifications
• AI Channels: 8 (simultaneously sample, differential or 50
Ω pseudo-differential)
• ADC Resolution: 24 bits (Delta-sigma)
• Sample Rate: 1 kS/s to 128 kS/s (with resolution ≤ 272.84
μS/s)
• Input Range: ±1, ±2, ±5, ±10 V
• Input Coupling: AC/DC, selectable per channel
• Input over-voltage protect
• Full auto-calibration
• Built-in anti-aliasing filter
• IEPE Excitation: Disabled, 2 mA, selectable per channel
• Board-to-board synchronization
• DI Channels: 1 (interrupt)
• DO Channels: 2
(For detail specifications, please refer to the user manual of
PCIE-1803)
General
• Bus Type: PCI Express x1
• I/O Connectors:
1 x 36-pin Mini-SCSI (for AI),
1 x HDMI (for clock, trigger, and DI/Os)
2 x IDC10 (for synchronization)
• Dimensions (L x H): 168 x 98 mm (6.6" x 3.9")
• Operating Temperature: 0 ~ 70 °C (32 ~ 158 °F)
• Storage Temperature: -40 ~ 80°C (-40 to 176°F)
• Storage Humidity: 5 ~ 95 % RH, non-condensing
Driver Installation
We recommend installing the driver before installing the
PCIE-1803 card to guarantee problem-free installation.
The Advantech DAQNavi Device Drivers setup program
or the PCIE-1803 can be downloaded from the Advantech
website (www.advantech.com). Follow the steps outlined
below to install the driver software.
1. Execute the PCIE-1803 driver package.
2. The driver installation program should be launched.
When the setup program is launched, a setup screen
will be displayed.
3. Click the "Next" button and wait for driver installation.
4. Click the "Finish" button to exit the setup program.
PCIE-1803 Startup Manual 1
