Summary of Contents for Moxa Technologies EDS-726 Series
- Page 1 Moxa EtherDevice Switch EDS-726 Hardware Installation Guide Second Edition, June 2008 © 2008 Moxa Inc., all rights reserved. Reproduction without permission is prohibited. P/N: 1802007260011...
- Page 2 Panel Layout of EDS-726 Series...
- Page 3 System status LEDs Push-button switch to select mode for Interface Module Interface Module mode LEDs Fast Ethernet Interface Module port LEDs Terminal block for 2 power inputs, 2 DIs, and 2 DOs Save and load buttons for CF card Serial Console port CF card socket Gigabit Ethernet Module LEDs Two cartridge receptors for Gigabit Ethernet Interface Modules...
-
Page 4: Mounting Dimensions (Unit = Mm)
Mounting Dimensions (unit = mm) 381.70 362.40 EtherDevice Switch EDS-726 Front View 106.63 149.15 362.40 401.00 Rear View Fast Ethernet Interface Modules 128.00 Side View Front View Side View Gigabit Ethernet Interface Modules 101.20 95.60 Side View Front View... -
Page 5: Din-Rail Mounting
DIN-Rail Mounting The DIN-Rail attachment plates are permanently fixed to the back panel of EDS-726. Do not attempt to remove the attachment plates, since doing so could damage the product STEP 1: STEP 2: Insert the top of the DIN-Rail into the The bottom of the DIN-Rail will snap notches at the bottom of the top array into place behind the DIN-Rail... -
Page 6: Wiring Requirements
NOTE Before tightening the screws into the wall, make sure the screw head and shank size are suitable by inserting the screw into one of the keyhole-shaped apertures of the Wall Mounting Plates. Do not screw the screws in all the way—leave about 2 mm to allow room for sliding the wall mount panel between the wall and the screws. -
Page 7: Wiring The Relay Contact
Keep input wiring and output wiring separated. It is strongly advised that you label wiring to all devices in the system when necessary. Grounding Moxa EtherDevice Switch Grounding and wire routing help limit the effects of noise due to electromagnetic interference (EMI). Run the ground connection from the ground screw, on the side panel of EDS-726, to the grounding surface prior to connecting devices. -
Page 8: Wiring The Digital Inputs
Wiring the Digital Inputs EDS-726 has two sets of digital input—DI 1 and DI 2. Each DI comprises two contacts of the 6-pin terminal block connector on EDS’s top panel. The terminal block is also used for EDS’s two DC inputs. Top and front views of one of the terminal block connectors are shown here. -
Page 9: 10/100Baset(X) Ethernet Port Connection
10/100BaseT(X) Ethernet Port Connection The 10/100BaseT(X) ports located on EDS-726’s front panel are used to connect to Ethernet-enabled devices. Below we show pinouts for both MDI (NIC-type) ports and MDI-X (HUB/Switch-type) ports. MDI Port Pinouts MDI-X Port Pinouts 8-pin RJ45 Signal Signal 1000BaseT Ethernet Port Connection... -
Page 10: Led Indicators
ST-Port Pinouts ST-Port to ST-Port Cable Wiring Cable Wiring ATTENTION This is a Class 1 Laser/LED product. To avoid causing serious damage to your eyes, do not stare directly into the Laser Beam. LED Indicators The front panel of Moxa EDS-726 contains several LED indicators. The function of each LED is described in the table below. - Page 11 The CF card is not in the CF slot or the CF card is not in FAT/FAT32 format. GREEN Blinking Loading or saving data to the CF card failed. The CF card is in the CF slot in FAT/FAT32 format. NOTE Use the Mode push-button switch to cycle among the LNK/ACT, SPEED, FDX/HDX, RING PORT, and COUPLER PORT LEDs.
-
Page 12: Specifications
Specifications Modular Managed Switch System, EDS-72610G Modular Managed Switch System with 6 slots, and up to 26 ports. PWR1 PWR2 FAULT SPEED FDX/HDX STAT LNK/ACT RING COUPLER MASTER COUPLER CF PORT PORT MODE EtherDevice Switch EDS-726 Technology Standards IEEE802.3, 802.3u, 802.3x, 802.1D, 802.1w, 802.1Q, 802.1p, 802.1X, 802.3ad, 802.3z Protocols IGMP Snooping, GMRP, GVRP, SNMP... - Page 13 IM-4MSC 7.2W IM-4MST 7.2W IM-4SSC 7.2W IM-1LSC/3TX IM-1GTX 2.5W IM-1GSXSC 1.5W IM-1GLXSC 1.5W IM-1GLHXSC 1.5W IM-1GZXSC 1.5W Overload Current Present Protection Reverse Polarity Present Protection Mechanical Casing IP30 protection Dimensions 362 x 146 x 128 mm (W x H x D) Installation DIN-Rail, Wall Mounting (optional kit) Gigabit Ethernet Interface Module, IM series...
- Page 14 Single mode: IM-1GLXSC 0 to 10 km, 1310 nm (9/125 μm, 3.5 PS/(nm*km)) IM-1GLHXSC 0 to 40 km, 1310 nm (9/125 μm, 19 PS/(nm*km)) IM-1GZXSC 0 to 80 km, 1550 nm (9/125 μm, 19 PS/(nm*km)) Min. TX Output 1M-GSX: -9.5 dB 1M-1GLX: -9.5 dB 1M-1GLHX:...
- Page 15 IM-4TX IM-4MSC IM-4MST IM-2MSC/2TX IM-2MST/2TX IM-1LSC/3TX IM-4TX IM-4MSC, IM-4MST IM-2MSC/ IM-2MST/ IM-1LSC/ IM-4SSC, IM-2SSC/ Interface LED Indicators PWR, P1, P2, P3, P4 port status RJ45 Ports 10/100/1000BaseT(X) auto negotiation speed, F/H duplex mode, and auto MDI/MDI-X connection Distance 100 m Fiber Ports 100BaseFX ports (SC/ST connector) Optical Fiber...
- Page 16 Ambient Relative Humidity 5 to 95% (non-condensing) Regulatory Approvals UL60950, UL 508, CSA C22.2 No. 60950, Safety EN60950 (Pending) UL/cUL Class I, Division 2, Groups A, B, C and D Hazardous Location (Pending) ATEX Class I, Zone 2, EEx nC IIC (Pending) FCC Part 15, CISPR (EN55022) class A EN61000-4-2 (ESD), Level 3 EN61000-4-3 (RS), Level 3...
