- Page 1 Installation and Operating Instructions Issue: 1 Robinhood Wall Canopy Rangehood Description: Model Numbers: WCAN60X (60cm S/S); WCAN60W (60cm White); WCAN90X (90cm S/S) WCAN60X WCAN60W WCAN90X...
-
Page 2: Table Of Contents
Due to continual product development, Robinhood reserves the right to alter specifications or appearances without notice. Important Safety Instructions..........................1 Appliance Details .............................. -
Page 3: Important Safety Instructions
Important Safety Instructions IMPORTANT: Read the assembly instruction section and safety precautions of this booklet carefully before removing the contents of this carton. 1. In certain circumstances electrical appliances may be a safety hazard. 2. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience or knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety. -
Page 4: Appliance Details
Appliance Details Voltage & Frequency: 220-240V 50Hz WCAN60X: 1 x 2W LED Lamp Max: WCAN60W: 2 x 2W LED WCAN90X: 2 x 2W LED WCAN60X: 102W Rated Input Power: WCAN60W: 214W WCAN90X: 214W General Information Before installing and operating the rangehood, carefully read the following important information regarding... -
Page 5: Installation
Installation Preparation Ensure that the rangehood is not connected to the power supply until after installation is complete. If you have an outlet leading outside, you can connect your rangehood, according to the image below, by means of an extraction duct (enamel, aluminium, flexible pipe or inflammable material) with an interior diameter of 150mm. The rangehood must be placed at least 65cm above the cooking surface. -
Page 6: Installation - Exhaust
Installation - Exhaust Fix the one-way valve to the air outlet of the rangehood, and then attach the exhaust pipe to the one-way valve. Chimney Installation Put the inner chimney piece inside the outer chimney. Slide the inner chimney up to the desired height. Fix it into place on plate I with two 4x8mm screws, as below. -
Page 7: Installation - Recirculation
Installation – Recirculation If you do not have a vent leading outside, the rangehood can be installed in recirculation mode. Activated carbon filters will be used to filter the air and recirculate it back into the room. Installation is similar to the installation method for exhaust above, but without the duct. -
Page 8: Operating Instructions
Operating Instructions On / Off Button Push to turn the fan on / off. Low Speed Push to set the fan to low speed. Medium Speed Push to set the fan to medium speed. High Speed Push to set the fan to high speed. Light Button Push to turn the light on / off. -
Page 9: Troubleshooting
Troubleshooting Fault Possible Cause Solution The fan blade is jammed. Light on, but fan Switch off the unit and have repaired by does not work qualified service personnel. The motor is damaged. Light bulb burnt out. Replace the bulb with correct rating. Neither the light nor the fan work Power cord loose. -
Page 10: Warranty Certificate (New Zealand)
The following conditions apply in respect of the warranty given in this certificate: Monaco Corporation Limited (“Monaco”) warrants the following Robinhood products against manufacturing defects and faulty materials, under normal use and subject to the exclusions in this certificate, for a period of: Rangehood, Ovens, Cooktops, Dishwashers, Refrigeration - 24 months from date of original purchase for domestic •... -
Page 11: Warranty Certificate (Australia)
• The product was used outdoors. All Robinhood Rangehoods are suitable for indoor use only and not suitable over BBQs or charcoal cookers designed for outdoor use. In addition, this warranty does not extend to damage or defects which in our opinion, directly or indirectly arise from or are due to: exposing the product to acidic or corrosive materials or chemicals such as dyes, solvents, denture cleaner or acetone;...
