R-Series V PROFINET RT & IRT
Temposonics
®
Operation Manual
3.2 Order code of Temposonics
1 2 3 4 5
R H 5
a b c
a Sensor model
R H 5 Rod
b Design
B Base unit (only for replacement)
J Threaded fl ange M22×1.5-6g (rod Ø 12.7 mm),
stroke length: 25...5900 mm (1...232 in.)
M Threaded fl ange M18×1.5-6g (standard)
S Threaded fl ange ¾"-16 UNF-3A (standard)
T Threaded fl ange ¾"-16 UNF-3A (with raised-face)
c Mechanical options
A Standard
B Bushing on rod end (only for design »M«, »S« & »T«)
M Thread M4 at rod end (only for design »M«, »S« & »T«)
V Fluorelastomer seals for the sensor electronics housing
d Stroke length
X X X X M 0025...7620 mm
Standard stroke length (mm)
25... 500 mm
500... 750 mm
750...1000 mm
1000...2500 mm
2500...5000 mm
5000...7620 mm
X X X . X U 001.0...300.0 in.
Standard stroke length (in.)
1... 20 in.
20... 30 in.
30... 40 in.
40...100 in.
100...200 in.
200...300 in.
Non-standard stroke lengths are available;
must be encoded in 5 mm/0.1 in. increments.
e Number of magnets
X X 01...30 position(s) (1...30 magnet(s))
RH5
®
6 7 8 9 10 11 12
d e
Ordering steps
5 mm
10 mm
25 mm
50 mm
100 mm
250 mm
Ordering steps
0.2 in.
0.4 in.
1.0 in.
2.0 in.
4.0 in.
10.0 in.
13 14 15 16 17
D 5 8 1 U
f g
f Connection type
8 2 × M12 female connectors (5 pin),
D 5
1 × M12 male connector (4 pin)
g System
1 Standard
h Output
1 PROFINET RT & IRT, position and velocity,
U 4 0
encoder profi le (1 position)
2 PROFINET RT & IRT, position and velocity,
U 4 0
MTS profi le (1...30 position(s))
1 PROFINET RT & IRT, position and velocity,
U 4 1
encoder profi le, internal linearization (1 position)
2 PROFINET RT & IRT, position and velocity,
U 4 1
MTS profi le, internal linearization (1...30 position(s))
NOTICE
• Select the MTS profi le (U402 or U412) in
position measurement.
• Specify the number of magnets for your application and order the
magnets separately.
• The number of magnets is limited by the stroke length.
The minimum allowed distance between magnets (i.e. front face
of one to the front face of the next one) is 75 mm (3 in.).
• Use magnets of the same type for multi-position measurement,
e.g. 2 × U-magnet (part no. 251 416-2).
• If the option for internal linearization (U411, U412) in
is chosen, select a suitable magnet.
I 6 I
18 19 20
4
h
h
"Output" for multi-
h
"Output"
