Parameter Description
This is used to specify which MIDI Channel is used to trigger cells. If the channel selected here is also
GlobalMIDI
chosen as the channel for a cell, the cell selection will override the global setting, and that channel will only
trigger the configured cell or cells. See section Use MIDI to Play a Cell Chromatically below for more
information.
The default value is Ch 10. You can choose a channel between 1 and 16, or choose None to ignore MIDI
inputs. Note that individual cells have a parameter that allows you to specify a different MIDI channel for
that cell. When the MIDI parameter for a cell is set to Default, the cell will respond to the channel that is
selected in this GlobalMIDI setting.
Compressor When set to On, bitbox will apply a compressor to the signals sent to Out1 and Out2.
MIDI PC When set to ON, bitbox will respond to MIDI program changes by opening the Preset that maps to the
specified program number. See Use MIDI to Play a Cell Chromatically below for more information.
Remember that bitbox does not automatically save changes. Therefore, when you change presets you will
lose any unsaved changes.
When you are done, press the HOME button to go back to the Main screen.

Working in Flipped Mode

When the value for Flip UI is set to ON, the user interface on the touch screen will be inverted. Use this setting when the
module is installed in a rack with the touchscreen on the bottom. When flipped, the firmware adjusts how the buttons, control
knobs and CV Trigger jacks are mapped to the user interface. One noteworthy change is that the HOME and INFO buttons
now reverse functions. This is done so that HOME is always on the left and INFO is always on the right. The alignment of the
control knobs in this mode is slightly high compared to the parameters on the touch screen. However, the top left control
knob will control the top left parameter, and the lower right control knob will control the lower right parameter. The CV trigger
inputs are also now mapped to the inverted display. The input jacks and output jacks maintain their original assignments. The
figure below shows the faceplate labels for an inverted module.
7/17/19 11:13:00 AM
Page 11 of 42
Inverted Faceplate Labels
