stretch touchscreen gestures to zoom in and out of the waveform, or swipe to scroll along the length of the waveform. You can
quickly jump to a different section of a long waveform by touching that section of the wave in the top view.

To Configure Basic Cell Parameters:

Now that you've chosen a WAV file to play, let's tell bitbox how you want to play it.
1. Touch the icon immediately to the left of the WAV file name at the top of the
screen to display the Cell Mode menu. Touch one of the options, Sample, Clip or
Slicer, to set the cell mode. The icon changes to represent the selected cell mode.
See the table at the beginning of this section for help in choosing the cell mode. If
you choose New Recording here instead, you will clear the WAV file assigned to
this cell and go back to the Load and Record screen.
2. From the Waveform screen, press the INFO button to display the first page of the
Cell Parameters screens. You can continue to press INFO to cycle through the Cell
Parameter screens and the Waveform screen.
3. On the first Cell Parameters screen, there are four menu items below the measure and beat count. The left most
item is the grid icon. The second menu item is the output selection button (Out1/2 in the example figure). Touch
this menu item to display the list of Output Options:
Output Description
Option
Out1/2 The output of this cell is sent to Out1 and Out2 in stereo.
Out1 The output of this cell is sent to Out1 in mono.
Out2 The output of this cell is sent to Out2 in mono.
FX1/2 The output of this cell is sent to FX1 and FX2 in stereo.
FX1 The output of this cell is sent to FX1 in mono.
FX2 The output of this cell is sent to FX2 in mono.
4. Touch the desired Output Option to select it.
5. The next menu item (Poly in the example figure) controls the polyphony of the cell. Touch the menu option to select
Polyphonic or Monophonic playback for this cell. Sample cells support 4-note polyphony. Clip mode and Slicer mode
support 2-note polyphony.
6. The last menu item displays the first few characters of the WAV file name. Touch this menu item to start playback of
the cell. The playback functionality will depend on the other parameter settings. The WAV file is playing when this
menu item is highlighted light blue.
7. On the first Cell Parameters screen you can configure some general cell options that are the same for all cell modes.
Touch the control knob closest to each parameter to set its value. Make sure you pay attention to the LaunchMode
parameter because this impacts how the cell responds to triggers.
7/17/19 11:13:00 AM
Page 15 of 42
Digital Heart – Analog Soul
Bitbox 2.5 User's Manual
Cell Parameters Screen Page 1
