Nanobox | Razzmatazz Quick Start Guide
GET SET UP
1.
Insert the microSD card. The card must be in the slot for razzmatazz to load. The card is spring-
loaded. Push to eject when needed, but leave it in for now.
2.
Connect the Line Out to your mixer, speakers or headphones.
3.
Connect an optional MIDI controller to the MIDI IN jack. TRS Type A and B are supported.
4.
Connect the USB power cable.
5.
Finger drum on the Pads Home screen or the MIDI controller and you are ready to make some
beats!
INTRODUCING NANOBOX | RAZZMATAZZ
PRESET NAME
Touch to load and save presets.
Menu
Copy and paste within
and across presets.
Drum Pads
Tap to trigger drum
hits. The violet pad
is selected.
HOME BUTTON
Go to the Pads
Home or the
Sequencer Home.
Trigger pads
with a MIDI
Controller on
notes C2 (36) -
G2 (43).
1 of 4
Oct 5, 2022
nanobox
LAYER BUTTON
Access the Mixer, Mutes
and FX Controls. Cycle
through pads or
sequence pages.
CLOCK
The current
Measure and beat.
LEFT ARROW BUTTON
Go back to the previous screen.
RIGHT ARROW BUTTON
Access more detail about the
current selection.
Master Volume
Turn the top knob
to adjust.
KNOBS
Top knob adjusts
master volume,
bottom knob
selects a pad.
