Dormakaba STV 1 Series Mounting Instructions

Contents
1 About this manual
2 Safety
3 Product description
4 Mounting
5 Assignment of terminals and switches
6 Dismantling and disposal
1 About this manual
1.1 Target group
The door lock STV 1xx must only be mounted by
trained electricians with specific knowledge of
electromechanical locks, fire safety codes and
regulations.
1.2 Intended use
The STV 1xx serves to keep doors securely closed, and
to open it without jamming and without delay in case
of emergency. The STV 1xx is used in the SafeRoute®
system.
1.3 Other applicable documents:
• System instructions for the used SafeRoute® license
• Operating instructions for the SafeRoute® system
• Inspection logbook
1.4 Symbols used
ATTENTION
This signal word indicates a situation of
potential risk, which could lead to damage
to property or the environment if not
averted.
TIPS AND RECOMMENDATIONS
This signal word indicates useful information
for efficient and trouble-free operation.
STV 1xx
Mounting instructions
1.5 Further labeling
1. 2.
Sequence of action steps
1
1
2
6
Reference to a chapter
2
5
5
Reference to another document
Door opening direction DIN left =
opening outwards to the right
Door opening direction DIN right =
opening outwards to the left
Components may be damaged by
electrostatic discharges
2 Safety
ATTENTION
Property damage by electrostatic discharge.
The control board may be damaged by an
electrostatic discharge!
• The user must ground his/her own body
before touching a component!
WN 059507 45532 – 2019-03
EN
