- Page 1 Saflok Quantum® Pixel Installation Instructions PK3693-T - 2019 - 02...
- Page 2 - Door prep jig only available for 1-3/8" [34.9mm] OR 1-3/4" [44.5mm] doors with standard centered lower mortise pocket and no rabbet. © 2018 dormakaba USA, Inc. All trademarks and registered trademarks are the property of their respective owners. Saflok Quantum Pixel...
- Page 3 #12 X 1-1/2 I/S Lever Assy #12-24X 3/8 Mortise Flat Head Screws O/S Lever Assy #12 X 1-1/4 Flat Head Screws #8-32 X 1/4 Flat Head Screws Mortise Face Plate Figure 2 - Door preperation jig Saflok Quantum Pixel PK3693_T 02-19...
- Page 4 LOWER MORTISE *UPPER MORTISE OFFSET TO O/S DOOR FACE IF GREATER THAN 1-3/4" DOOR THICKNESS. *CENTERED FOR 1-3/8" TO 1-3/4" DOOR THICKNESS. PAGE 4 - STRIKE PREP PAGE 3 - UPPER *NOT TO SCALE CONTROLLER MORTISE Saflok Quantum Pixel PK3693_T 02-19...
- Page 5 (see figure #6 for wire channel location) d. Secure with included #12 flat head screws Ensure wire harness is free and not pinched Figure 5 - Lock Exploded View with Mounted Controller and Mortise Saflok Quantum Pixel PK3693_T 02-19...
- Page 6 Connect the harnesses from the mortise and controller together *Do not seat the slide tray in door at this point Figure 6 - Wire Channel in Door Edge Wire Channel Figure 7 - Controller and Mortise Harness Connection Saflok Quantum Pixel PK3693_T 02-19...
- Page 7 Connect the battery to the PCB. Green LED should flash 4 times b. Present a valid keycard to the reader. Red and green LEDs will flash and motor will activate Seat the tray into the controller being careful to not pinch any wires Saflok Quantum Pixel PK3693_T 02-19...
- Page 8 I/S Lever Assy I/S Lever Rose 5. Lever Set Installation (If supplied by dormakaba) a. Place the outside lever rose assembly on the outside of the door b. Place the inside lever rose assembly on the inside of the door Secure to the outside rose assembly using the included shoulder screws d.
- Page 9 Thumb Turn Thumb Turn Base Head Screws 6. Thumb Turn Installation (If supplied by dormakaba) a. Align base centered over the mortise cam (not hole in door) b. Mark hole centers using center punch to ensure alignment is maintained Drill small pilot hole with a short depth to aid in securing the screws d.
- Page 10 Place the lens onto the base and rotate clockwise to secure at 6:00 Ensure cover is secured (locking tab will click when fully seated) *For ease of assembly and disassembly; wrap thumb around circumference of cover to get a good grip Figure 14 - Reader Cover Installation Saflok Quantum Pixel PK3693_T 02-19...
-
Page 11: Removing The Cover
Rotate cover counter-clockwise while maintaining upward pressure on locking tab *A32360 Cover removal tool can be attached to HH6 programming cable or keychain Figure 15 - Cover Removal Tool Alignment Programming Keychain Hole Cable Slot Cover Removal Tool Alignment A32360 Cover Removal Tool Saflok Quantum Pixel PK3693_T 02-19... - Page 12 Note: If bumpers or other seals are added after strike plate installation and causes alignment and latch problems, it is the property’s responsibility to correct this condition. This note generally applies to new construction or new door installation. Saflok Quantum Pixel PK3693_T 02-19...
- Page 13 L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Saflok Quantum Pixel PK3693_T 02-19...
- Page 14 USA Inc. Customer Services & Support Saflok: 1.800.999.6213 / + 1.248.837.3700 General information: dormakaba.us Online consumable orders: www.saflokstore.com To access all of our easy steps, please visit our support website: www.dormakabalodgingsupport.com www.dormakaba.com...
