Mocka Vibe Coffee Table Assembly Instructions Manual

Vibe/Olsen Coffee Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
C
A B
bolt locking dowel
x18 nut x18 x12 screw x14
H I
CR runner DL
tracks x2 runners x2
Hardware Supplied
Phillips & Flathead screwdrivers required
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
D
E F
long screw small CL runner
x12 screw x20 tracks x2
J K
DR allen key cover
runners x2 x1
WARNING: Any furniture that is not anchored to a wall has the potential to tip
over in certain circumstances, i.e. if a child attempts to climb up on the furniture
G
or in the event of an earthquake. Accordingly, we recommend that all furniture
is anchored to a wall. We supply a free safety wall anchor with all furniture sold
and we recommend these are used to prevent your product tipping. The fixing
device provided should fit most wall types, but please note that different wall
materials may require different fixing devices from those supplied.
L
x2
*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
Please clear any loose wood from the locking nut holes before inserting the nut to ensure it locks 100%.
1
