Do not open during installation
This product is factory-sealed.
Refer to the instructions contained in this
document for details.
Surge Protection
This product features built-in surge protection circuitry in compliance with
applicable standards.
For comprehensive protection of a luminaire installation against lightning and
electrical surges, it is essential to cover mains supply and data input lines at
the distribution board level, by using respective primary (Type 1) and secondary
(Type 2) surge arrestors in compliance with EN61643-11/IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and activated
prior to luminaire installation. Also, disconnect luminaires before operating
high-power devices such as, for example, electrical arc welders.
WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Projector
FLD121 #1 LED
FLD131 #1 LED
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for WE-EF FLD121 #1
Summary of Contents for WE-EF FLD121 #1
- Page 1 WE-EF LEUCHTEN Installation and Maintenance Instructions Projector FLD121 #1 LED FLD131 #1 LED Do not open during installation Surge Protection This product is factory-sealed. This product features built-in surge protection circuitry in compliance with Refer to the instructions contained in this applicable standards.
- Page 2 Projector FLD121 #1 FLD131 #1 IP66, Class I, ta = 40°C Mounting Accessories Flat sur ace tter SF-FLD1 for FLD121/131 #1 145-9535 Colu n tter CF-FLD1 for FLD121/131 #1 145-9536 SF-FLD1 CF-FLD1...
-
Page 3: Maintenance
Light Source Maintenance Apart from cleaning the product’s exterior surfaces, no special maintenance work is required. Do not use high-pressure cleaners. In case of component failure due to abnormal circumstances or at end of life, replacement must be carried out Warning: Do not open luminaire while mains supply is switched on. -
Page 4: Installation
Installation The product must be installed and maintained by a building/construction and/or electrical regulations and relevant legislation. Warning: Switch off mains electrical supply prior to installing and connecting the luminaire. Notice: than the original manufacturer, then the warranty will no longer be valid and shall become the full respon- sibility of the modifying person/organisation. - Page 5 Installation Procedure Installation Flat sur ace tter 1) Switch off mains electrical supply. 2) Detach strain relief clip K Attention: Keep strain relief clip K for locking cable later (in step 5). Feed cable C from luminaire A through pivot I and hole L 4) Loosen screw M H (do not turn it...
- Page 6 5) Clamp strain relief clip K on cable C and press 6) Check that rating shown on luminaire label into hole L T. Ensure the conforms with mains electrical supply. strain relief clip K is properly placed in position 04/19 IP66 to lock the cable.
- Page 7 Installation Procedure Installation Colu n tter 1) Switch off mains electrical supply. D and cable entry hole F. Drill relevant holes E and F on column X. Ensure cable entry hole F has B in position. 4) Loosen screws M H (do not turn out) Insert and tighten screws D.
- Page 8 5) Feed cable C from luminaire A through pivot I 6) Check that rating shown on luminaire label on column X, while connecting luminaire A conforms with mains electrical supply. H over 04/19 IP66 pivot I. Turn luminaire A towards object to H is properly FLD121-LED 220-240V50-60/Hz...
- Page 9 Tel +1 724 742 0030 Fax +41 22 752 49 74 Fax +1 724 742 0035 info.switzerland@we-ef.com info.usa@we-ef.com WE-EF LIGHTING United Kingdom Tel +44 844 880 5346 Fax +44 844 880 5347 info.uk@we-ef.com TO9210W0419 © WE-EF 2019 subject to change.
