1-12

Tributary Configuration

Terminal

In a terminal, 28 DS1 circuits are allowed. They are Trib A1 to Trib A28.

Table 1-1: Tributary configuration for a terminal

Slot
1
2
3
4
5
6
7

Repeater

A repeater configuration can have A (Trib A) and B (Trib B) directions. Trib A
goes to the "A" radio, and Trib B goes to the "B" radio. Up to 16 DS1 signals can
be transmitted to the "A" radio, and up to 16 DS1 signals can be transmitted to
the "B" radio.

Table 1-2: Tributary configuration for a repeater

Slot
1
2
3
4
5
6
7
8
Constellation™
M12 Trib
M12-1 Trib A1 - A4
M12-2 Trib A5 -A8
M12-3 Trib A9 - A12
M12-4 Trib A13 - 16
M12-5 Trib A17 -A20
M12-6 Trib A21 - A24
M12-7 Trib A25 - A28
M12 Trib
M12-1 Trib A1 - A4
M12-2 Trib A5 -A8
M12-3 Trib A9 - A12
M12-4 Trib A13 - 16
M12-5 Trib B1 -B4
M12-6 Trib B5 -B8
M12-7 Trib B9 - B12
M12-8 Trib B13 - B16
