7-2

SOURCE Timed

Source Timed Configurations

Select Source timed in the following cases.
• In a repeater system where the Modem units are not the same (that is,
• In a loop system, when the HLM is at a master site, the HLM must be
• Terminal configuration.
From the Keypad menu, select
CONFIGURATION > SYSTEM > SYNCHRONIZATION MX > SOURCE
CONFIGURATION > SERVICE CHANNEL > LOCAL OFF HOOK > ENABLE
Constellation™
one is 115072 and the other is 115430), ensure that the system
synchronization is set to SOURCE timed.
set to SOURCE timed.
If the HLM is set for SOURCE timed, select enable local
off hook for the Service Channel.
