5.6 Bürkert-Communicator software
The MassFlowCommunicator is another PC software that
is not compatible with the product. You cannot use the
PC-software MassFlowCommunicator to configure or
operate the product.
The Type 8920 Bürkert-Communicator is a PC-software and
enables the following actions, for example:
• Setting the parameters of the product, for example the basic
settings for the product start-up
• Running the diagnostics, and read the error memories for
example
• Updating the product software
• Adjusting the user-defined calibration curve
To use the Type 8920 Bürkert-Communicator software, do the
following steps:
→ Buy the USB-büS-interface set with article number 00772551
from Bürkert.
→ Download the latest version of the Type 8920 Bürkert-Com-
municator software from www.burkert.com
→ Install the Bürkert-Communicator software on a PC. During
installation, the büS stick must not be inserted at the PC.
→ Assemble the parts of the USB-büS-interface set. Refer to
Fig. 4.
14
English
8742 Profibus, 8742 Analogue
Description
Fig. 4: Assembled parts of the USB-büS-interface set with article
number 00772551
→ Set the termination-resistance switch of the büS stick to ON.
→ Insert the büS stick into a USB port of the PC.
→ Energize the product. Refer to chpt. 8 Electrical installation.
→ Insert the micro-USB connector into the büS-interface for the
Bürkert Communicator software. The location of the büS-in-
terface on the product is given in chpt. 5.1 on page 10
→ Wait until the Windows pilot of the büS stick has been com-
pletely installed on the PC.
→ Start the Bürkert-Communicator software.
→ Click on
in the Bürkert-Communicator software to esta-
blish the communication between the Bürkert-Communicator
software and the product. A window opens.
→ Select büs-stick.
