Mechanical Installation

2 Mechanical Installation

2.1 Dimensions and Weight

255 mm/10 in
98 mm/
3.8 in
216 mm/8.5 in
196 mm/7.7 in
374 mm/
14.7 in
Illustration 2.1 Dimensions
®
VLT Inverter Scroll CDS 801 Operating Instructions
®
MG10V402 - VLT is a registered Danfoss trademark
394 mm/15.5 in
2 2
